Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Specifications
Power source :
Three Phase AC Motor
Impeller Testing :
Dynamic Blancing Adjusting
Mounting :
Free Standing
Noise :
Optional
Warranty :
1 Year
Characteristics :
Large Volume, High Efficiency
Current Type :
AC
Brand Name :
SIMO
Model Number :
SIMO Blower 5-10
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
300-5000 USD
Payment Terms :
T/T,L/C,Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Blade :
Forward / Backward/Backward Curved
Bearing cooling :
Air cooling or Circulating Water cooling
Description
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems

The induced draft fan is a key component of a coal-fired boiler system. Its operating performance directly affects flue gas flow, furnace pressure, auxiliary power consumption and overall boiler efficiency.

SIMO 5-10 induced draft fans are designed for industrial boiler flue gas handling and ID fan applications, with configurations available for high dust loading, wear and continuous operation.

For existing boiler systems, SIMO can also evaluate the current fan and operating conditions to determine whether a fan upgrade or system retrofit can improve efficiency and operating stability.

Common Operational Challenges
Challenge Impact
High energy consumption Increased electricity costs and low efficiency
Severe wear from dust and ash Short equipment lifespan and frequent replacement
Unstable airflow Poor combustion efficiency and inconsistent output
Frequent maintenance and downtime Production interruptions and higher maintenance costs
Performance Specifications
Parameter Range Unit
Pressure range 1638 - 10707 Pa
Air flow range 9890 - 709000 m³/h
Impeller diameter 710 - 1600 mm
Speed 480 - 1450 rpm
Material Specifications
Component Materials Notes
Blower fan casing Q235, Q345, stainless steel Design as special
Blower fan shaft 45# steel, Q304, SS304, SS316L -
Blower fan impeller Q304, 12Cr1Mov, 15Crmov, 15MnV -
Medium 10 - 120°C Dustiness <80 g/m³, incombustible
Motor ABB, WN, SIMO, LA IP 54,55,56, 3 phase
Optional Components
System base frame
Protective screening
Silencer
Inlet & Outlet pipeline compensator
Inlet & Outlet flange
Damper
Electric actuator
Shock isolator
Diaphragm coupling
Fluid coupling
Motor rain cover
Temperature sensor
Vibrating sensor
Soft starter
Inverter
Special Electrical Motor
System monitoring Instrument
Lube system
Overhead lube tank
Our Comprehensive Solution
  • System performance evaluation
  • Fan selection and aerodynamic redesign
  • Wear-resistant material upgrade
  • Energy efficiency optimization
  • Installation and commissioning support
Our engineering team ensures that each solution is optimized for maximum performance and minimum operating cost.
Why Choose SIMO BLOWER
  • Over 70 years of industrial fan manufacturing experience
  • Strong customization capabilities for complex applications
  • Complete in-house testing (performance, vibration, durability)
  • Proven solutions across multiple industries
  • Fast technical response and professional support
Customer Applications
Energy-Saving Induced Draft Fan for Coal-Fired Boiler Systems
Frequently Asked Questions
What parameters need to be provided when you design the industrial centrifugal fans?
Air flow, total pressure or static pressure, inlet temperature, local voltage and frequency, Altitude etc. If there is flammable and explosive gas, or big dust loading in the medium, please also inform the designer.
How about your company's pre-sales service and after-sales service?
Before our cooperation, we have the professional technical team to help you make the technical solution according to your working condition, to make sure the centrifugal fan efficiency operation. After sales service, we will offer 12 months' repairing service, and provide lifelong follow-up services. Besides, our engineers are available for going abroad to offer the repairing service.
Does your company have qualifications?
SIMO Blower has obtained ISO 9001-2008, CE, BV certifications and so on.
