Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 9-08
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Application :
Industrial Ventilation
Drivetrain :
Direct/Coupling Driven/V-belt Driven
Motor type :
Three Phase AC Motor
After-sales Service Provided :
Field installation, commissioning and training
Impeller Support :
SWSI (Single Width, Single Inlet), Impeller overhung
Power source :
Three Phase AC Motor
Description

Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan

Introduction Of Centrifugal Fan

The 9-08 series high pressure fan is generally used for forging furnace and high pressure forced ventilation, and can be widely used to transport materials, transport air and non-corrosive, non-self-igniting, non-viscous substances gas.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
9-08 7.1D 2900 10635～12427 12292～19360 75～110
8D 1450～2900 3249～15955 8792～27696 18.5～200
9D 1450 4181～4869 12518～19717 30～45
10D 1450 5065～6143 17172～30052 55～75
11.2D 960～1450 3031～7747 15973～42221 30～132
12.5D 960～1450 3450～9713 22206～58695 45～250
14D 960～1450 4341～12285 31197～82463 75～400
16D 960～1450 5696～16250 46569～123090 185～850


Product Features

1.The fan can output higher gas pressure, and can provide more gas flow at the same time, low noise.

2. In the case of using the common base, the installation is very simple and basically does not require the support of professional technicians.

3. The motor shaft is elastically connected with the drive shaft. It is not necessary to tighten the belt or replace the belt frequently, and the maintenance workload is small.

FAQ

1,Q: What’s the MOQ of your company?

A: The MOQ is 1set.

2,Q: How long is the delivery time?

A : A:5-35 days.

3,Q : What’s your payment terms?

A : T/T, L/C, or Negotiable.

4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?

A: We have our own factory, our type is factory +trade.

Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan

Double Suction High Pressure Backward Metallurgy Stainless Steel Blower Fan
