Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 9-03
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Application :
Industrial Ventilation
Drivetrain :
Direct/Coupling Driven/V-belt Driven
Bearing :
SKF/FAG/By your demand
Power source :
Three Phase AC Motor
Lubrication :
Oil bath lubrication
Impeller Support :
SWSI (Single Width, Single Inlet), Impeller overhung
Description

Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan

Introduction

9-03 series fan-type iron furnace special high-pressure centrifugal fan, is suitable for IL/h, 2L/h, 3L/h, 3L/h, 7L/h melting rate of iron furnace blast performance requirements.

The fan can also be used as the blast for various furnace forging furnaces.

It is also suitable for conveying air and non-corrosive, non-self-igniting, non-viscous materials or light powder/debris/short fiber materials.

Product Features

1. The motor uses high-efficiency and energy-saving motors from China's leading motor manufacturers (and can also install branded motors required by users), with reliable quality and lower energy consumption.

2. It is made of high quality carbon steel, stainless steel or other metal materials are available upon request.

3. The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.

4.After the completion of production, after running test and vibration value detection, the operation is reliable.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
9-03 8D 2950 16680～17631 3019～8117 37～55
9D 2950 21348～22314 4326～11632 75～110

FAQ

1.Q: What’s the MOQ of your company ?

A: The MOQ is 1set.

2.Q: How long is the delivery time ?

A:5-35 days.

3.Q : What’s your payment terms ?

A : T/T, L/C, or Negotiable.

4.Q: What’s your warranty ?
A: 1 year.

5.Q: Is your company factory or trade company ?

A: We have our own factory, our type is factory +trade.

Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan

Single Suction 16Mn Backward Curved Lime Kiln Flue Gas Blower Fan
