High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 4-14
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Application :
Industrial Ventilation
Pressure :
Low Pressure Blower
Voltage :
380V
Motor type :
Three Phase AC Motor
Weight :
150 KG
Noise :
Optional
Description

High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems

Introduction

This single inlet metallurgy centrifugal fan is designed for industrial ventilation and metallurgy airflow systems requiring large air volume and stable low-medium pressure performance.

The forward curved impeller design improves airflow efficiency and supports smooth air transportation in furnace ventilation, metallurgy workshops, industrial boilers, and large-scale industrial air systems.

Manufactured with Q235 carbon steel, the fan is suitable for continuous industrial operation and adaptable to different airflow system layouts.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
4-14 8C 1450 2177～1481 16985～30134 18.5
9C 960 ~ 1450 824 ~ 2756 16011～42906 11 ~ 30
10C 730 ~ 1450 588 ~ 3403 16701 ～58856 7.5 ~ 55
11.2C 730 ~ 1450 736 ~ 4276 23464 ～82688 11 ~ 90
12.5C 730 ~ 1450 912 ~ 5325 32619 ～114952 22 ~ 160
14C 730 ~ 1450 1147 ~ 6678 45827～161499 37 ~ 315
16C 580 ~ 960 951 ~ 3825 54351～159606 45 ~ 160


FAQ

1,Q: What’s the MOQ of your company?

A: The MOQ is 1set.

2,Q: How long is the delivery time?

A : A:5-35 days.

3,Q : What’s your payment terms?

A : T/T, L/C, or Negotiable.

4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?

A: We have our own factory, our type is factory +trade.

Application

Centrifugal fan is applied in industrial boiler, (centrifugal fan can be applied in industrial boiler,) it also can be applied in industrial kilns, blast furnace, Industrial waste heat recovery device, Electrolytic aluminium production line air purification system and other industrial work environment.

High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems

High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air SystemsHigh Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air SystemsHigh Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air SystemsHigh Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems

High Volume Metallurgy Centrifugal Fan for Industrial Ventilation and Furnace Air Systems
