Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 9-08
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Material :
Carbon Steel/Alloy Steel/Stainless Steel
Feature :
High Performance
Blade :
Forward / Backward/Backward Curved
Current Type :
AC
Lubrication :
Oil bath lubrication
Description

Carbon Steel Single Suction Anti-Explosion Smoke Exhaust Flue Gas Fan

Introduction

The 9-08 series high pressure fan is generally used for forging furnace and high pressure forced ventilation, and can be widely used to transport materials, transport air and non-corrosive, non-self-igniting, non-viscous substances gas.

The temperature of the medium generally does not exceed 50 ° C (maximum not more than 80 ° C). The dust and hard particles contained in the medium are not more than 150 mg/m3.

For flammable and explosive gas transportation, the impeller can be processed with aluminum alloy to prevent sparks during operation.

Product Features

1.The fan is made of high quality carbon steel, and can also use stainless steel or other metal materials according to customer requirements.

2. Running test and vibration value detection after the production is completed, the fan operation is reliable.

3.The fan can output higher gas pressure, and can provide more gas flow at the same time, low noise.

4. In the case of using the common base, the installation is very simple and basically does not require the support of professional technicians.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
9-08 7.1C 2900 10635～12427 12292～19360 75～110
8C 1450～2900 3249～15955 8792～27696 18.5～200
9C 1450 4181～4869 12518～19717 30～45
10C 1450 5065～6143 17172～30052 55～75
11.2C 960～1450 3031～7747 15973～42221 30～132
12.5C 960～1450 3450～9713 22206～58695 45～250
14C 960～1450 4341～12285 31197～82463 75～400
16C 960～1450 5696～16250 46569～123090 185～850


FAQ

1.Q: What’s the MOQ of your company ?

A: The MOQ is 1set.

2.Q: How long is the delivery time ?

A:5-35 days.

3.Q : What’s your payment terms ?

A : T/T, L/C, or Negotiable.

4.Q: What’s your warranty ?
A: 1 year.

5.Q: Is your company factory or trade company ?

A: We have our own factory, our type is factory +trade.

Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion

Carbon Steel Single Suction Smoke Flue Gas Exhaust Fan Anti Explosion
