A girth gear (also called ring gear) is a large-diameter, heavy-duty gear assembly mounted on the shell of rotary kilns, ball mills, dryers, and other rotary equipment. It meshes with the pinion shaft to transmit driving torque and drive the cylinder to rotate smoothly under heavy load.


Heavy Duty Large Girth Gear for Rotary Kiln and Ball Mill

Functions

· Transmit high torque from the pinion shaft

· Drive the rotary kiln or ball mill to rotate continuously

· Support stable operation under heavy impact and fatigue load

· Ensure low noise and long service life

Materials

· High-strength alloy cast steel: ZG42CrMo, ZG35CrMo, ZG45Mn2

· High hardness, good toughness, excellent wear resistance

Features

· Cast or forged structure

· Precision machined and ground teeth

· High accuracy and good meshing performance

· Usually half or quarter split structure for easy installation

· Heat treated for high strength and durability

Applications

· Cement rotary kilns

· Ball mills, raw mills, coal mills

· Lime kilns, metallurgical kilns

· Dryers, rotary coolers, agglomerators

No.

Item Name

Material

Technical Description

Drawing No.

1

Girth gear

42CrMo

Open-die forging, fabricated in four segments; dimensions and technical requirements as per drawing

4301.02.100 Quarter segment: 4301.02.101

2

Pinion

35CrMo

Forged structure; dimensions, parameters and requirements as per drawing

4310.13.201

3

Shell section under girth gear with transport supports

Q345B

Dimensions: φ7000 × 3200 mm Plate thickness: 60 mm

–

4

Spring plate

Q345B

Manufactured in accordance with drawings

–

5

Fastening components (connecting girth gear & spring plate)

45# steel

Manufactured in accordance with drawings

–

General Notes

· All parts manufactured in accordance with the drawings.

· Production shall commence only after confirmation of the drawings by the customer.
