Signal Coaxial Cable 670-086 / 25 with Tin Soaked Copper Braiding for Waterproof
Signal Coaxial Cable 670-086 / 25 with Tin Soaked Copper Braiding for Waterproof
Specifications
Place of Origin :
China
Brand Name :
KINGTONE OR OEM
Certification :
ISO, CE, RoHS, UL
Model Number :
670-086 / 25 Semi Flexible Cable
MOQ :
5 KM
Packaging Details :
100M, 200M, 300M, Wooden Spool, Carton
Delivery Time :
Normally 15 days
Payment Terms :
T/T, L/C
Supply Ability :
50*20’GP / Month
Condcutor :
Silver Plated Copper Clad Steel
Dielectric :
PTFE
Shield :
Tin Soaked Copper
Jacket :
FEP
Package :
100M, 200M, 300M, Wooden Spool, Carton
Description

Signal Coaxial Cable 670-086 / 25 with Tin Soaked Copper Braiding for Waterproof

Quick Detail:

  • 670-086 / 25 Semi Flexible Cable
  • 0.93mm Silver Plated Copper Clad Steel
  • Dielectric:1.65mm PTFE
  • Outer Conductor: 2.1mm Tin Soaked Copper
  • Low SWR (1.25:1 to 40GHz typical)
  • Excellent Shielding Effectiveness
  • Precising Phase Matching

Applications:

Military airborne,shipboard, and landbased microwave communications,electronic warfare and radar

systems.

Commercial communications infrastructure.

Mobile terminals.

Commercial and military satellites.

KT0803 670-086/25 Semi Flexible Cable,1.65mm PTFE,0.93mm Silver Plated CCS
Construction Parameters:
Inner Conductor 0.93mm Silver Plated Copper Clad Steel
Dielectric 1.65mm PTFE
Outer Conductor Nom.2.1mm Tin Soaked Copper Braid
Electrical Characteristics:
Capacitance 190.4 pF/m
Impedance 25 Ω
Velocity of Propagation 0.695
Operating Frequency (GHz) 50
Time Delay(ns/m) 4.7
Max. Operating Voltage (kVrms) 1.5
Mechanical and Environmental:
Min. Bending Radius (mm) 6
Min.Repeated Bending Radius (mm) 20
Operating Temp.(℃) -55 to +125 ℃
Attenuation(20℃):
Frequency (GHZ) Attenuation (dB/100m) Power(Watts CW)
0.5 59.00 195.00
1.0 84.00 128.00
5.0 196.00 55.60
10.0 286.00 36.50
20.0 423.00 25.30
Order Informations:
Marking KINGTONE 670-086/25 XXX M (or Per customer's request)
Inner Package 100m/Roll, 100m/Spool,305m/Spool (or Per customer's request)
Outer Package Carton, Color Box, Pallet (or Per customer's request)
Delivery time Normally 15 days after received the deposit.
More informations please contact with us.

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

A, Incoming material inspected by QC.

B, Manufacturing Process Control

C: Workers trained daily/weekly/monthly

D: Work instructions manual at each work station

E: 5S system implemented

F: Machine maintenance procedure

G: Quality Control and Final Inspection

The QC staff will check the material, process product

and final product according to the specification or test procedure.

2, Our R&D efforts center on reinforcing and developing element technologies

needed to support the future growth and success for customers and KINGTONE.

3, We know customers have urgent needs.

We are skilled at effective communication to interact with customers.

In order to provide prompt service, we can answer for you 7*24 hours.

4, We can Quickly and professionally answer for the inquire

5, More than 1000 kinds of cable, connectors and assembles can be produce and organized from us

6, Intime delivery
