2MP 2mp IR Bullet Camera IR Small Bullet Analogue Camera
2MP 2mp IR Bullet Camera IR Small Bullet Analogue Camera
2MP 2mp IR Bullet Camera IR Small Bullet Analogue Camera
2MP 2mp IR Bullet Camera IR Small Bullet Analogue Camera
Specifications
Brand Name :
KAIDUN
Model Number :
KDM-EX-FL228IR02(A)
Certification :
ECM ATEX/BS EN62676-1-1-2014
Place of Origin :
China
MOQ :
1
Packaging Details :
Wooden box packaging / cardboard box packaging
Delivery Time :
5-8 week
Payment Terms :
T/T
Supply Ability :
5000 units/year
Material :
Stainless Steel 304 or 316L
Ingress Protcetion :
IP68
Power :
DC12V±25%
Dimensions(L*W*H) :
170*140*139mm
Net Weight :
2.5kg
Infrared Distance :
30m
Description

2MP Explosion Proof Anti-Corrosion IR Small Bullet Analogue Camera

Key Features

  • 2.8mmfxedlens(3.6mm/6mm/8mm/12mm etc optonal)Max.IR Length 30m,SmartIR.,Max30fps@1080P;CVI/CVBS/AHD/TVIswitchable
  • 4 Signals over 1 Coaxial Cable:HDCVI technology supports 4 signals to be transmited over 1 coaxial cable simultaneously,i.e.video,
    audio,data and power.Dual-way data transmissionallows the HDCVI camera to interact with the XVR,such as sending control signalor triggering alarm.Moreover,HDCVI technology supports PoC for constructon fexibility.
  • Long Distance Transmission:HDCVI technology guarantees real-tme transmission at long distance without any loss.It supports up to
    800m(1080p)/1200m(720P)trans-mission via coaxal cable,and up to 300m(1080P)/450m(720P)via UTP cable.
  • Simplicity:HDCVI technology inherits the born feature of simplicity from traditonal analog surveillance system,making itself a best choice
    for investment protecton.HDCVI system can seamlessly upgrade the traditonal analog system without replacing existng coaxial cabling.The plug and play approach enables full HD video surveillance without the hassle of confguring a network.
  • Smart IR:The camera is designed with IR LEDilluminaton for best lowlight perfor-mance.Smart IR is a technology to ensure brightness
    uniformity in B/W image under lowiluminaton.Dahua's unique Smart IR adjusts to the intensity of camera's infrared LEDs to compensatefor the distance of an object,and prevents IR LEDs from overexposing images as the object come closer to the camera.
  • Mult-formats:The camera supports multple video formats including HDCVI,CVBS and other two common HDanalog formats in the market.
    The four formats can be switched over through oSD menu or by PFM820(UTC controller).This feature makes the camera to be compatble withmost end users'existng HD/SD DVRs.
  • Mult-anguage OSD:OSD menu provides multple image adjustments and functon setngs to meet the requirements of diferent monitoring scenes.
    The OSD menu includes confguratons such as backlight mode,day/night,white balance,privacy mask and moton detect.The camera supports 11languages for OSD menu,namely,Chinese,English,French,German,Spanish,Portuguese,talian,Japanese,Korean,Russian and Polish.
  • Protecton :The camera's outstanding reliability is unsurpassed due to its rugged de-sign.The camera is protected against water and dust with
    IP69K ranking,making it suitable for outdoor extreme environments.With working temperature range of-40℃to+80℃,the camera is designedfor extreme temperature environments.Supportng±30%input voltage tolerance,this camera suits even the most unstable power supplyconditons.Its 4KV lightning ratng provides protecton against the camera and its structure from the efects of lightning.

Application Scenarios

Other application areas:desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.

Service

You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.

Specification

Camera
Image Sensor 1/2.7inch CMOS
Effective Pixels 1920(H)×1080(V),2MP
ScanningSystem Progressive
Electronic Shutter Speed PAL:1/25s-1/100000s
NTSC:1/30s-1/100000s
S/N Ratio 65dB
Minimum lumination 0.02Lux/F19,30IRE,OLux IR on
FillLlight Working 10-30m
IR On/Off Control Auto;
IR LED Number 1Powerfullight
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8mm;(3.6mm/6mm/8mm/12mm etc optional)
Max Aperture F1.9
Field of View 2.8mm:119°*101*54°
(diagonal*horizontal*vertical)
3.6mm:100°*84°*45°
(diagonal*horizontal*vertical)
Iris Type Fixed iris
Close Focus Distance| 2.8mm:0.5m(1.7ft)
3.6mm:0.8m(2.6ft)
Lens Detect Observe Recognize Identify
2.8mm 386m 15.4m
(50.5ft)		 7.7m 3.9m
(126.6ft) (25.3ft) (12.8ft)
3.6mm 49.7m 19.9m 9.9m 5m
(163.1ft) (65.3ft) (32.5ft) (16.4ft)
Video
Frame rate CVI:1080P@25/30fps;720P@25/30fps;720P@50/60fps;
AHD:1080P@25/30fps;720P@25/30fps;
TVI:1080P@25/30fps;720P@25/30fps;720P@50/60fps;
CVBS:960H
Resolution 1080P(1920*1080);720P(1280*720);960H(960*576/960*480)
Day/Night Auto switch by ICR
BLC BLC/HLC/DWDR
WDR DWDR
Whtie Balance Auto;manual
Gain Control Auto:manual
Noise Reduction 2D NR
Smart IR Yes
Electronic Defog Yes
Mirror off/on
Privacy Masking off/on(8 area,rectangle)
General
Power DC 12V±25%
Dimensions(L*W*H) 170*140*139 mm
Net Weight 2.5kg
Material Stainless Steel 304 or 316L
Working Environment -40℃~60℃,Humidity:≤95%RH(non-condensing)
Strorage Environment -40℃~60℃,Humidity:≤95%RH(non-condensing)
Surge Protection 2KV
Ingress Protection IP68
Infrared Distance 30m
Approval
Protection IK08(IEC62262:2002),IP68(IEC 60529-2013)
Explosion-Proof Protection ATEX:II2G Ex db IIC T6 Gb/II 2D Ex tb IIC T80℃ Db IP68
For explosive gas atmospheres,the maximum surface temperature is 85℃;
For flammable dust atmospheres,the maximum surface temperature is 80℃;IIC:for explosive
gas atmospheres other than mines susceptible to firedamp;For explosive gas mixture
atmospheres:Zone 1,Zone 2,Zone 21,Zone 22.
Verification to BS EN 62676-1-1-2014-Video surveillance systems for use in security applications

Certificate
