4X Optical Marine CCTV Auto 2MP PTZ Dome Camera
4X Optical Marine CCTV Auto 2MP PTZ Dome Camera
4X Optical Marine CCTV Auto 2MP PTZ Dome Camera
4X Optical Marine CCTV Auto 2MP PTZ Dome Camera
Specifications
Brand Name :
KAIDUN
Model Number :
MC500
Place of Origin :
China
MOQ :
1
Packaging Details :
Wooden box packaging / cardboard box packaging
Delivery Time :
5-8 week
Payment Terms :
T/T
Supply Ability :
5000 units/year
Material :
Stainless Steel 316L or 304
Resolution :
2MP
Focal Length :
2.8-12mm,4x optical zoom
Dimesions(L*W*H) :
201*182*135mm
Power :
DC12V;POE(802.3af)
Weight :
4kg
Working Distance :
10mm-1500mm(wide-tele)
Description

2MP Marine PTZ Dome Camera


Key Features

  • Stainless Steel 316L Enclosure
  • IP68 Ingress Protection
  • High quality imaging with 2 MP resolution
  • 4x optical zoom allows for closerviewing of subjects in expansive areas
  • Up to 20m IR range ensures safety at night
  • DC12V/PoE Power optional


Service


You can have the product replaced within 7 days due to quality problem and the quality guarantee period for this product is one year.
You can also get the favorable promotions.
In the following conditions the product is not considered within the quality guaranteescope:
- Client cannot bring forth the quality guarantee card and invoice or receipt of purchasing;
- Improper service conditions,such as unmatched power,ambient temperature,humidity or lightingcaused malfunction;
- Malfunction caused by accident,negligence,disaster incorrect operation or network attack;
- Malfunction or damage in installation,repair,modification or dismantle caused by unauthorizedpersonnel;
- Out of guarantee period.
If you have any dissent on technical service provided by distributor,please lodge acomplaint to the customer's service center of Kaidun.
The quality guarantee card will be validated only after it's stamped by the after-service provider.


Application Scenarios


Container Vessel, Bulk Vessel, Oil tanker, cruise Vessel, Yacht, Oil/Gas Drilling Platform,Oil Depots, Sea Port

Other application areas: desert drill sites,offshore rigs,mechanical engineering,biogas plants,military,electric power,hydraulic power,railway,metallurgy,natural gas extraction,drilling platform,aerospace,marine,armed police,border defense,vessels,fireworks production,ports etc.


Specification


Camera Module
Image Sensor 1/3"progressive scan CMOS
Min.Illumination Color:0.005 Lux @(F1.6,AGC ON)
B/W:0.001 Lux @(F1.6,AGC ON)
0 Lux with IR
White Balance Auto/Manual/ATW(Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp
Gain Auto/Manual
Shutter Time 50Hz:1/1 s to 1/30,000 s
60Hz:1/1 s to 1/30,000 s
Day &Night IR Cut Filter
Digital Zoom 16×
Privacy Mask 24 programmable privacy masks
Focus Mode Auto/Semi-automatic/Manual
WDR 120 dB WDR
Lens
Focal Length 2.8 mm to 12 mm,4×optical zoom
Zoom Speed Approx.2s(optical lens,wide-tele)
Field of View Horizontal field of view:100.5°to 32.6°(Wide-Tele)
Vertical field of view:52.8°to 18.3°(Wide-Tele)
Diagonal field of view:120.2°to 37.5°(Wide-Tele)
Working Distance 10 mm to 1500 mm(wide-tele)
Aperture Range F1.6 to F2.7
PTZ
Movement Range(Pan) 0°to 355°
Pan Speed Configurable,from 0.1/s to 100°/s.Preset speed:100°/s
Movement Range (Tilt) 0°to 90°
Tilt Speed Configurable,from 0.1/s to 100°/s.Preset speed:100°/s
Proportional Zoom Yes
Presets 300
Power-off Memory Yes
Compression Standard
Video Compression Main Stream:H.265+/H.265/H.264+/H.264
Sub-stream:H.265/H.264/MJPEG
Third Stream:H.265/H.264/MJPEG
H.264 Type Baseline profile/main profile/high profile
H.264+ Yes
H.265+ Yes
Video Bitrate 32 Kbps to 16384 Kbps
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bitrate 64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 Kbps to 192 Kbps(MP2L2)
SVC Yes
Smart Features
Basic Event Motion Detection,Video Tampering Detection,Exception
Smart Event Face detection,intrusion detection,line crossing detection,region entrance detection,region exiting detection,object removal detection,unattended baggage detection,audio exception detection
Smart Record ANR(Automatic Network Replenishment),dual-VCA
ROI Main stream,sub-stream,and third stream respectively support four fixed areas.
IR
IR Distance 20 m
Smart IR Yes
Max.Resolution 1920×1080
Main Stream 50Hz:25fps(1920×1080,1280×960,1280×720)
60Hz:30fps(1920×1080,1280×960,1280×720)
Sub-Stream 50Hz:25fps(704×576,640×480,352×288)
60Hz:30fps(704×480,640×480,352×240)
Third Stream 50Hz:25fps(1280×720,704×576,640×480,352×288)
60Hz:30fps(1280×720,704×480,640×480,352×240)
lmage Enhancement 3D DNR,EIS,Regional Exposure,Regional Focus
Network
Network Storage Built-in memory card slot,support microSD/SDHC/SDXC,up to 256 GB;NAS(NFS,SMB/CIFS),ANR
Alarm Linkage Alarm actions,such as Memory Card Video Record,Trigger Recording,Notify Surveillance Center,Upload to FTP/Memory Card/NAS,Send Email,etc.
Protocols Pv4/IPv6,HTTP,HTTPS,Qos,FTP,SMTP,UPnP,SNMP,DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,DHCP,PPPoE,Bonjour
API ONVIF (Profile S,Profile G,Profile T),ISAPI,SDK
Simultaneous Live View Up to 20 channels
User/Host Up to 32 users.3 user levels,administrator,operator and user
Security Measures User authentication (ID and PW),Host authentication (MAC address);HTTPS encryption;IEEE 802.1x port-based network access control;IP address filtering
Client iVMS-4200,Hik-Central,Hik-Connect
Web Browser IE8 to 11,Chrome 31.0+,Firefox 30.0+,Edge 16.16299+
Wi-Fi
Standard IEEE802.11b,802.11g,802.11n,transmission distance:50 m(without interference)
Frequency Range 2.400 GHz to 2.483 GHz
Channel Bandwidth 20/40 MHz
Security 64/128-bit WEP,WPA/WPA2,WPA-PSK/WPA2-PSK,WPS
Transmission Rate 11b:11Mbps;11g:54Mbps;11n (20MHz):150Mbps;11n(40MHz):300Mbps
Interface
Audio Interface 1-ch audio input (mic in/line in)and 1-ch audio output (line out) 1 built-in microphone
Network Interface 1 RJ4510 M/100 M Ethernet,PoE
Power Output 12 VDC,max.60 mA
General
Power DC 12 V;PoE (802.3af)
Dimension Ø182mm×135mm
Weight 4kg
Operating Condition -40°C to 60℃.Humidity 100% or less(non-condensing)
DORI
Detection Distance 130.9m
Observe Distance 51.9m
Recongize Distance 26.2m
Identify Distance 13.1m
