2 Channels 2.0Kw CCD Camera Wheat Sorting Machine
2 Channels 2.0Kw CCD Camera Wheat Sorting Machine
2 Channels 2.0Kw CCD Camera Wheat Sorting Machine
2 Channels 2.0Kw CCD Camera Wheat Sorting Machine
Specifications
Brand Name :
Hons
Model Number :
S2
Certification :
CE、SGS、ISO9001
Place of Origin :
Anhui China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
600Set/Sets Per Month
Delivery Time :
10-15 Work Days
Packaging Details :
Wood Packaging
Name :
6SXM-126(CCD)
Capacity(T/h) :
1.5~2.5
Voltage(V) :
AC220V/50Hz
Power(Kw) :
≤2.0
Weight(Kg) :
500(±5%)
Dimension(L*W*H mm) :
1220*1620*1550
Color :
White
Channels :
2
Application :
Sorting
Product name :
Vegetable Sorting Machine
Description

2 Channels 2.0Kw CCD Camera Wheat Sorting Machine


Features:

1. 5000 pixels CCD camera,HD recognition,high speed,identify refinement,good stability;

2. Most advanced LED light,good stability,long life used,low power consumption;

3. Humanized touch panel, easy to learn, more convenient to operate;

4. Powerful software,separate sorting modes with storage and memory function;

5. Matching different specifications chutes for different materials;

6. High frequency electromagnetic valve,can use up to 1.6 billion times;

7. Original imported switch power source, passed 3C authentication.


Technical Parameter

Model S1 S2 S3 S4 S5 S6 S7 S8 S10 S12
Capacity(t/h) 0.8~2.0 1.2~2.5 1.5~3 3~6 4~7 5~8 6~10 7~11 7~15 10~18

Voltage

(V)

 AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz AC220V 50/60Hz
Power(KW) ﹤1.5 ﹤2 ﹤2.4 ﹤2.6 ﹤3.0 ﹤3.6 ﹤4.0 ﹤4.6 ﹤5.5 ﹤7.0

Air pressure

(Mpa)

 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8 0.6-0.8

Dimension

(mm)

910*

1620*1550

1220*

1615*1550

1628*

1595*2040

1870*

1595*2040

2210*

1595*2040

2528*

1595*2040

2836*

1595*2040

3152*

1595*2040

3910*

1595*2040

4594*

1595*2100
Weight (Kg) 350 500 800 1000 1250 1400 1600 1800 2250 2700

Sorting materials

Rice: rice/brown rice/sticky rice/millet/sorghum/myotonin/back rice

Beans:kidney bean/soybean/mung/red bean/black bean/pea/broad bean/coffee bean/lentil/chickpea

Tea:green tea/back tea/dark tea/white tea/yellow tea
Cereals:corn/barlley/wheat seed/pepper seed/onion seed

Nuts&Kernels: sunflower seed/pumpkin seed/watermelon seed/cashew nut/peanut/pistachio

Dehydrated vegetables:pepper/garlic flake/carrot granule/onion/cabbage

Idustril goods: quarta sand/recycled plastic/salt/mineral/monosodium glutamate/white sugar/pill/pearl
Economic crops:raisin/medlar/lilly/red date/shrimp bran/tobacco/agaric
2 Channels 2.0Kw CCD Camera Wheat Sorting Machine

About us

1. The leading photoelectric detection and classification equipment supplier.

2. W supply optic detection and classification equipment as rice color sorting machine, grain CCD color sorter machine,grain color sortingmachine,grain color sorting machine, tea color sorting machine,belt color sorting machine ect,and also offfer the effective fast solution for relative industry.

3.Hons+ brand series product have been popular both in domastic and oversea market many years, we have exported over than 20 countries with high praise from customers.
