Low Self Discharge 12V Lead Acid Battery With M6 Terminal Energy Saving
Low Self Discharge 12V Lead Acid Battery With M6 Terminal Energy Saving
Specifications
Brand Name :
Champion
Model Number :
6FM50
Certification :
CE ; UL
Place of Origin :
China
MOQ :
Negotiation
Price :
negotiation
Payment Terms :
30% in advance
Supply Ability :
350,000 pieces per month
Delivery Time :
25 days
Packaging Details :
Carton box
Model Name :
6FM50 12V Lead Acid Battery
Feature :
Energy Saving
Voltage :
12V
Terminal :
M6
Capacity :
50AH
Color :
Black or other
Weight :
15kg
Application :
Solar,UPS
Description

Low Self Discharge 12V Lead Acid Battery With M6 Terminal Energy Saving


Description:

12V 50AH gel lead acid battery,agm vrla battery Specification

Nominal Valtage12V
Nominal Capability50Ah@10 hour rate F.V.(1.8v/cell)
Approx. Weight15Kg
TerminalsB2 (Fitting M8 bolt & nut) I2 is optional
Internal Resistance ≤7.5m Ω(Fully Charged)
Max. Discharge Current500A (5 sec)
Max. Charge Current12.5A
Operating Temperature Range

Charge: -10°c~40 °c (-14°F~104 °F)
Discharge: -20 °c ~50°c (-4°F~122 °F)
Storage: -20 °c ~40 °c (-4 °F~104 °F)

Self DischargeAbout 3% of capacity declined per month at (25 °c )

Place of Origin:
Guangdong, China (Mainland)
Brand Name:CHAMPIONModel Number:
12V50AH
Usage:
UPS
Voltage:
12v
Sealed Type:
Sealed
Maintenance Type:
Free
Size:
229*138*210
Weight:
15KG
Nominal Capacity:
50AH
Low self discharge::
no charge six months storage at room temperature
Safety:
There are no internal relief valve isolation sparks explosion
Long life::
3-5 years normal use
Vrla Agm battery lead::
99.994% purity lead
Color::
Grey or Black
Container Material::
ABS
Certification::
UL,CE,ISO9001,ISO14001
Delivery time ::
25days


Specifications:

Noninal Voltage12V
Capacity(10HR,25℃)50AH
Designed Life10 Years
DimensionLength228mm
Width138mm
Height210mm
Total Height224mm
Reference Weight15kg

Charateristics


Capacity 25℃ (77℉) To 1.70V/Cell
10 hr rate(5.5A)50Ah
5 hr rate(8.8A)39Ah
1 hr rate(33A)28Ah
Inner Resistance(fully charged 25℃)6.5mΩ
Self-discharge (at 25℃.) :3% of the capacity per month
Discharge Temperature-20~60℃
Charge Temperature-10~60℃
Storage Temperature-20~60℃
Cyclic charging voltage (at 25℃)14.4~14.9V
initinal current (at 25℃) 20A
Temperature Compensation-30mV/℃
Float Use (at 25℃)13.6-13.8V
Temperature Compensation (at 25℃)-20mV/℃


Competitive Advantage:


• Living Up to Prevailing Standards
• Good deep discharge cycle capability
• Excellent Recovery from Deep Discharge
• Longer Service Life
• High Reliability and Quality

Low Self Discharge 12V Lead Acid Battery With M6 Terminal Energy Saving
