Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries
Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries
Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries
Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries
Specifications
Brand Name :
Champion
Model Number :
6FM9G
Certification :
CE ; UL
Place of Origin :
China
MOQ :
Negotiable
Price :
negotiation
Payment Terms :
30% in advance, T/T
Supply Ability :
1,000,000 pieces per month
Delivery Time :
25 days
Packaging Details :
Carton box
Model Name :
6FM9G Lead Acid Storage Battery
Size :
151*65*94 mm
Voltage :
12V
Terminal :
Lead Acid Gel Cell Batteries
Capacity :
9AH
Color :
Black
Weight :
2.5kg
Application :
Industrial
Description

Industrial Lead Acid Storage Battery , Lead Acid Gel Cell Batteries


Lead Acid Storage Battery Applications:

1) Communication Systems: Switch, Microwave Stations, Mobile Base Stations, Data Centers, Radio and Broadcasting Stations.

2) Motivity Field: Robots, Electric Toys, Electric Tools & Portable Vacuum Cleaners

3) Solar & Wind Power Generation Systems

4) Signal System & Emergency Lighting Systems

5) EPS & UPS Systems


Lead Acid Storage Battery Specification:

Product Name

12v 9ah battery

Capacity
(25°C)

20HR(10.5V)

9Ah

10HR(10.5V)

8.4Ah

1HR(9.60V)

5.8Ah



Dimension

Length

151±1.5mm (5.94inch)

Width

65±1mm (2.56inch)

Height

94±1mm (3.70inch)

Total Height

100±1mm (3.94inch)

Approx. Weight

2.5kg

Terminal type

F1/F2

Internal resistance
(Fully charged, 25°C)

Approx. 19mΩ


Capacity affected by temperature (20HR)

40°C

102%

25°C

100%

0°C

85%

-15°C

65%


Self-discharge
(25°C)

3 month

Remaining Capacity: 91%

6 month

Remaining Capacity: 82%

12 month

Remaining Capacity: 65%

Nominal operating
temperature

25°C±3°C(77°F±5°F)

Operating temperature range

Discharge

-15°C~50°C(5°F~122°F)

Charge

-10°C~50°C(14°F~122°F)

Storage

-20°C~50°C(-4°F~122°F)


Float charging voltage(25°C)

13.60 to 13.80V
Temperature compensation:
-18mV/°C


Cyclic charging voltage(25°C)

14.50 to 14.90V
Temperature compensation:
-30mV/°C

Maximum charging current

2.7A

Terminal material

Copper

Maximum discharge current

135A(5 sec.)

Designed floating life(20°C)

3~5 years

Lead Acid Storage Battery Advantage:

  1. Sealed and maintenance free, safety, no leakage
  2. ABS containers and covers optional
  3. With safety valve
  4. Made by No 8 largest battery factory in China
  5. High quality and reliability
  6. Exceptional deep discharge recovery
  7. Flexible design for multiple installation
  8. Wide operating temp. range
  9. High capability, high energy density
  10. Long service life
