Hybrid UPS 2v500ah Deep Cycle Solar Lead Acid Battery Gel Battery Power Station
Hybrid UPS 2v500ah Deep Cycle Solar Lead Acid Battery Gel Battery Power Station
Hybrid UPS 2v500ah Deep Cycle Solar Lead Acid Battery Gel Battery Power Station
Hybrid UPS 2v500ah Deep Cycle Solar Lead Acid Battery Gel Battery Power Station
Specifications
Brand Name :
Champion
Model Number :
GFM500
Certification :
CE ; UL
Place of Origin :
China
MOQ :
50 pcs
Price :
negotiation
Payment Terms :
30% in advance, T/T
Supply Ability :
50,000 pieces per month
Delivery Time :
25 days
Packaging Details :
Carton box
Model Name :
GFM500
Size :
241*175*330 mm
Voltage :
2V
Terminal :
M8
Capacity :
500AH
Color :
Black
Weight :
30kg
Application :
UPS,Inverter,Solar system
Description

Hybrid UPS 2v500ah deep cycle solar lead acid battery gel battery power station

Description:

  • Gel condition: The effect of sealed reaction is over 99.9%.
  • Minor self-discharge.
  • Long service lift: The designed lift is over twelve years.
  • Good deep charge cycle performance.
  • Good over-discharging recovery performance.
  • Widely working environment.

Applications:

Offline or standby UPS

Diesel rotary UPS

Online UPS

Line-interactive UPS

DC power UPS

Hybrid (double conversion on demand) UPS

On grid power

Off grid power

Solar power

Specifications:

Noninal Voltage 2V
Capacity(10HR,25℃) 500AH
Designed Life 15 Years
Dimension Length 242mm
Width 175mm
Height 330mm
Total Height 365mm(T11) 345mm(T19)
Reference Weight 30.0kg

Charateristics

Capacity 25℃ (77℉) To 1.70V/Cell

 20 hr rate 520Ah
10 hr rate(20A) 500Ah
5 hr rate(32A) 400Ah
1 hr rate(120A) 3000Ah
Inner Resistance(fully charged 25℃) 2.5mΩ
Self-discharge (at 25℃.) : 3% of the capacity per month
Discharge Temperature -20~60℃
Charge Temperature -10~60℃
Storage Temperature -20~60℃
Cyclic charging voltage (at 25℃) 14.4~14.9V
initinal current (at 25℃) 60A
Temperature Compensation -30mV/℃
Float Use (at 25℃) 13.6-13.8V
Temperature Compensation (at 25℃) -20mV/℃

Model

Voltage

Capacity

Dimension(mm)

Terminal

Weight

(V)

(Ah)

L

W

H

TH

Type

(Kg±3%)

GFM100

2

100

171

72

205

210

F13

5.6

GFM150

2

150

171

102

206

221

F13

8

GFM200

2

200

171

111

330

364

F12

12.8

GFM250

2

250

171

111

330

364

F12

13

GFM300

2

300

171

151

330

364

F12

18

GFM350

2

350

171

151

330

364

F12

20

GFM400

2

400

210

175

330

367

F12

25

GFM500

2

500

241

175

330

365

F12

30

GFM600

2

600

302

175

330

367

F12

36

GFM630

2

630

302

175

330

367

F12

37

GFM650

2

650

302

175

330

367

F12

38

GFM800

2

800

410

175

330

367

F12

50

GFM1000

2

1000

475

175

330

367

F12

60

GFM1250

2

1250

475

175

330

367

F12

60

GFM1500

2

1500

400

350

345

382

F12

93

GFM1875

2

1875

400

350

345

382

F12

95

GFM2000

2

2000

490

350

345

382

F12

120

GFM2500

2

2500

490

350

345

382

F12

120

GFM3000

2

3000

710

350

345

382

F12

180

Competitive Advantage:

1> Sealed, maintenance free.

2> Design life: 15 years (floating charge).

3> Reliably Sealed and Leakproof Construction.

4> ABS(V0 optional) container materials.

5> High reliability, CE, UL and ISO certified.

6> Low self-discharge, less than 3% of capacity per month at 25°C

7> Safety valve installation for explosion proof

8> High tolerance against extreme temperature applications

9> Excellent pricing

Hybrid UPS 2v500ah Deep Cycle Solar Lead Acid Battery Gel Battery Power Station
