Specifications
Brand Name :
Casun
Model Number :
86SHD4101-160NK-EB0505
Certification :
CE,ROHS,ISO
Place of Origin :
China
MOQ :
5PC
Price :
$46-50$
Payment Terms :
D/A, T/T, L/C, D/P
Supply Ability :
10000+PCS+Month
Delivery Time :
7-15 days
Packaging Details :
Carton:38x29x18cm
Holding Torque :
4.5 N.m
Voltage :
3.48 V
Current :
4 A
Body Length :
110 mm
Weight :
2.3 kg
Phase Resistance :
0.87 ohm ±10% （At 20℃）
Shaft Length :
160 mm
Phase :
2
Insulation Class :
Class B
Description

Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5 N.m Big Tough CE RoHS Certificated from Casun Motor

The Casun NEMA 34 Hybrid Stepper Motor with Brake delivers high torque (4.5N.m) and reliable braking performance for industrial applications. Operating at 24V DC, this rugged motor is built for demanding environments while meeting CE & RoHS certifications.

Features:

  • Bipolar or unipolar versions available

  • Hybrid stepper construction

  • Available in single or double shaft versions

  • CE and RoHS approved

  • Customizations on request

Dimensions

Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor

Motor Specifications

Step Angel

 1.8°

Frame Size

 110 mm

Number of Phase

 2 Phase

Rated Current

 4 Amp

Holding Torque

 4.5 N.m

Resistance

 0.87 ohm

Inductance

 7.3 mH

Rotor Inertia

 1400 g.cm²

Motor weight

 2.3 kg

Connection

 Bipolar

Operating Specifications

Motor

Step Angle: 1.8°

Maximum Temperature: 80°C maximum

Ambient Temperature: -20 °C to 50°C

Storage Temperature -20: °C to 100°C

Humidity Range: 85% or less, non-condensing

Magnet Wire Insulation: Class B 130 deg C

Insulation Resistance: 100M Ohm at 500 VDC

Dielectric Strength: 500 VDC for 1 min

Encoder

Voltage: 5 v

Output: A + A - B + B - Z + Z -

Submodels

Nema 34 Hybrid Stepper Motor with Brake 24V DC 4.5N.m Big Tough CE RoHS Certificated from Casun Motor

Download

If our standard motor cannot meet your needs,

we can customize the motor according to your needs


Customized content includes but is not limited to special shafts, winding parameters, installation dimensions, lead wires with special requirements, connectors, etc.

Options:
Encoder | Brake | Gearbox | Shaft
