OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction
OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction
OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction
OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction
Specifications
Brand Name :
SHUANGXING
Model Number :
Customized
Certification :
ISO
Place of Origin :
HEBEI CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 MT / MONTH
Delivery Time :
15 DAYS
Packaging Details :
WOODEN CASE OR PALLET ,OR IN BULK
Use :
drainage area such as garden facilities
Capacity :
500mt/ month
Size :
Customized Size
Color :
black
Service :
Customized OEM
Product name :
gully grating
Description

OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction

Product Name
drain grate
Material Composition
Iron,Ductile iron
sealed
single or double
lock
available
Shape&Size
round,square or customized
Color Option
according to customer's requirement
Application
Be widely used in Inspection wells of power,telecommunication,mobile communication,fuel Sewer,gas pipes,gas station,chemical bases,urban arteries,high-grade highways,expressways,freight transport piers,airports,etc.
Surface Treatment
Painting, Powder coating, spraying, galvanization, chrome plating
type
Weight type: Applicable to urban roads and fast lanes.
normal type: Applicable to Driveway
Certificates
ISO

Item
Description
Frame size (mm)
Clear opening (mm)
Height (mm)
Unit weight (kg/pc)
Square type grating
1
 C250 Square type grating
300*300
170*170
45
9
2
C250 Square type grating
400*400
270*270
45
15
3
C250 Square type grating
500*500
370*370
50
23
4
C250 Square type grating
550*550
420*420
50
27
5
C250 Square type grating
600*600
470*470
55
31
6
C250 Square type grating
700*700
570*570
60
48
7
D400 Square type grating
500*500
370*370
80
32
8
D400 Square type grating
550*550
420*420
80
38
9
D400 Square type grating
600*600
500*500
80
43
10
D400 Square type grating
700*700
570*570
80
58
11
D400 Square type grating
700*700
600*600
100
95

3) product used

The product was used for the roads / idewalk / highway / airport

OEM Ductile Iron Rain Water Drain Grates B125 En124 For Municipal Construction

Product advantage

1. Moderate weight and easy installation

2. No inherent scrap value thus reducing risk of theft

3. 30 years of service life

4. Can be used in -30℃ to 70 ℃ degrees environment

5. Corrosion resistance, meet the needs of environmental protection, and reduce the exploitation of mining resources; beautify the city, classify the coloring, and enhance the taste of the city.

6. Tested by national security agencies. Compressive, bending and impact resistant. Heat, cold, acid, etc.
