High Safety Carton Box Stitching Machine with 1-5mm Stitching
High Safety Carton Box Stitching Machine with 1-5mm Stitching
High Safety Carton Box Stitching Machine with 1-5mm Stitching
High Safety Carton Box Stitching Machine with 1-5mm Stitching
High Safety Carton Box Stitching Machine with 1-5mm Stitching
High Safety Carton Box Stitching Machine with 1-5mm Stitching
Specifications
Brand Name :
hh
Model Number :
2000
Place of Origin :
china
Certification :
CE ISO
MOQ :
1
Price :
Negotiated
Payment Terms :
T/T
Supply Ability :
60 sets every month
Delivery Time :
5-8 DAYS
Packaging Details :
plastic
Nail Distance :
30-120mm
Stitch Thickness :
1-5mm
Origin :
Hebei Province
Process Board Qty :
Single Piece
Stitch Length :
1-5mm
Working Speed :
120 Nails
Stitching Width :
Customizable
Description

Product Description:

1. servo drive, precision, mechanical transmission part reduction, can effectively reduce the mechanical failure rate.

2.weilun touch screen operation, parameters (nail distance, nail number, nail type, backboard) easy to change.

3.the whole control system adopts PLC control system

4.rear electric baffle, driven by stepping motor, accurate size, more convenient and fast size conversion.

5.relays are all made by Chit

6.photoelectric and proximity switches adopt chit brand.

7.bottom die, the blade is made of Japanese tungsten steel (wear-resisting).

8.the whole set of nail head are all made of special steel, computer gong precision processing.

9.single stitching /, double stitching //, reinforcing stitching (// // // // / double stitching at both ends and single stitching at the middle part) can be finished in one time, which can meet different requirements of

Features:

  • Product Name: Carton Box Stitching Machine
  • Origin: Hebei Province
  • Other Name: Box Stitcher Carton Box Making Machine
  • Process Board Qty: Single Piece
  • Stitching Power: Low Power Consumption
  • Size Of Shape: 3500*1700*1550mm

Technical Parameters:

Stitch Length 1-5mm
Stitching Width Customizable
Nail Distance 30-120mm
Voltage 220V
Stitching Power Low Power Consumption
Process Board Qty Single Piece
Stitch Thickness 1-5mm
Origin Hebei Province
Working Speed 120 Nails
Other Name Box Stitcher Carton Box Making Machine
