Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3
Specifications
Brand Name :
Cartesykj
Model Number :
CTDCG-3
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
$4,323.00 - $43,239.00/sets
Payment Terms :
L/C,T/T
Supply Ability :
1 Set/Sets per Month
Delivery Time :
20~25 working days
Packaging Details :
Wooden packing
Name :
Automobile Chassis Dynamometer
Car Fitment :
BMW - Europe
Warranty :
12 Months
Port :
Guangzhou
Maximum axle-load (kg) :
3000
Maximum absorption power (kw) :
160
Maximum braking torque (Nm) :
1600
Maximum testing speed (km/h) :
130
Working voltage (current) :
96V ×35A
The power supply :
220V ±10% 50HZ
Description
Cartesy brand 4T light vehicles Chassis Dynamometer machine Horse Power Machine CTDCG-3



Product description:

Vehicle chassis dynamometer is mainly used for vehicle dynamics property, emissions and fuel consumption, (used in conjunction with fuel consumption meter, fuel consumption meter etc.) test, can complete car economy experiment, dynamic experiment and reliability experiment about special experiment and auto transmission system, chassis power output can be detected, torque, speed, distance, acceleration time, sliding distance and other data. So it divided in two kind of chassis dynamometer.

Features:

1. through high precision dynamic balancing, surface coating roller have high joint strength, abrasion resistance, adhesion coefficient is 0.92 or higher

2. Equipped with adjustable gear wheel, in order to guarantee the front drive vehicles test do not produce lateral slip; safe and reliable

3. With fuel consumption meter can be measured load condition of fuel consumption

4. The body is made of high quality flat MS Windows machine, ability is all ready, friendly interfaces, strong networking and it is convenient

5. Retrieve testing data, automatically print the results


Technical parameters

Model CTDCG-3 CTDCG-10 CTDCG-13


Maximum axle-load (kg)

 3000 10000 13000


Maximum absorption power (kw)

 160 250 300


Maximum braking torque (Nm)

 1600 2500 3000


Maximum testing speed (km/h)

 130 130 130


Drum diameter x length (mm)

 ∮216×1000 ∮318×1000 ∮373×1000


center distance (mm)

 480 495 600


Inside the drum width/width (mm)

 700/2700 700/2700 700/2700


Working voltage (current)

 96V ×35A 96V ×35A 96V ×35A


The power supply

 220V ±10% 50HZ 220V ±10% 50HZ 220V ±10% 50HZ
