Specifications
Brand Name :
Cartesysj
Model Number :
CTDCG-3-4WD
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
$8,998.00 - $169,497.00/sets
Payment Terms :
L/C,T/T
Supply Ability :
1 Set/Sets per Month
Delivery Time :
20-25 working days
Packaging Details :
Wooden packing
Name :
Automobile Chassis Dynamometer
Car Fitment :
BMW - Europe
Warranty :
12 Months
LOAD :
4t
Model Name :
CTDCG-3-4WD
Port :
Guangzhou
Working voltage (current) :
96V ×35A
The power supply :
220V ±10% 50HZ
Description

Cartesykj Australia 4WD 1000hp Vehicle Chassis Dynamometer horse power machine Vehicle Test Lane Vehicle inspection equipments


Product description:

The 4WD horsepower dynamometer is specially used to measure the chassis dynamic performance of the2WD and 4WD vehicles. It can not only accurately measure the dynamic performance at each speed, but also simulate the road to carry out the road test of routine and multi-road of the vehicles, and can also be used for vehicle refitting and ECU debugging and calibration , etc.


Technical parameters:

Model CTDCG-3-4WD CTDCG-10 CTDCG-13


Maximum axle-load (kg)

 3000 10000 13000


Maximum absorption power (kw)

 160 250 300


Maximum braking torque (Nm)

 1600 2500 3000


Maximum testing speed (km/h)

 130 130 130


Drum diameter x length (mm)

 ∮216×1000 ∮318×1000 ∮373×1000


center distance (mm)

 480 495 600


Inside the drum width/width (mm)

 700/2700 700/2700 700/2700


Working voltage (current)

 96V ×35A 96V ×35A 96V ×35A


The power supply

 220V ±10% 50HZ 220V ±10% 50HZ 220V ±10% 50HZ
