Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
Specifications
Brand Name :
Lsailt
Model Number :
LLT-GM-VER3.7.7
Certification :
CE ROHS
Place of Origin :
shenzhen,guangdong
MOQ :
1 set
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
20000piece per year
Delivery Time :
7 working days after received your payment
Packaging Details :
Cartons
Price :
negotiation
Suit for car model :
2015-2020 GMC Canyon Intellilink System
OS :
Android 10 System
RAM :
4GB
ROM :
64GB
CPU model :
RK3399
MAP :
GOOGLE MAP/IGO
Installtion :
plug and play
Warranty :
1 year
Carplay :
Wireless and Wired
Android Auto :
wired and wireless
Description

Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System

Android Configuration
Resolution 800X480
Display LVDS Digital(Latest chip)
SYSTEM: Android OS10
RAM: 4GB
EMMC: 64GB
CPU MODEL Dual-core ARM Cortex-A72 1.8GHz and Quad-core ARM Cortex-A53 1.4GHz RK3399
WIFI: 2.4 / 5Ghz
BT: BT5.0 Support calls and music and OBD date
CP / AA Wireless and Wired
Mirrorlink Wireless and Wired
HiCar YES
Play Store: Yes
GPS UBLOX GPS Module
DSP 256 DSP chip, with 16 period of EQ of DSP chip, the adjustable emperor, etc
Split Screen Support
UI Choose 5 sets for optional
Hardware Configuration
TF Card : Maximum support 64GB (Product not include TF Card)
Navi Sound Addsmall speakers. If don’t listen radio, navi sound from original car speakers.
AV IN: DTV
HD-MI OUT: Support 720P
Camera/ AHD: 4 CAMinput(guideline and radar )
Reversing DET Gray REAR-C
USB Port

3 ways

USB:CP and Update OS

USB1 / USB2 : ADAS and Media Player
GPS Module GPS and Beidou dual-mode GPS (BDS/UBLOX)
Special Function
MCU and APP Update: Online upgrade via WIFI
Cold start Time: 30 seconds
Hot Start: 6 seconds
Sleep: (Cycle 5 times and restart once)
Sleep memory Remember Last APP in parking
Installation Method Plug and Play
Multimedia Control
Microphone: Use OEM
Steering Wheel: Support up and down song, Vol DisPlay
Forced Reset MODE Button(Long press 5 seconds)
OEMBT in Android: Automatically return to the OEM BT screen
A/C DISP Support in the Android interface display
Speed Control: Adding camera is effective below 20KM

Functions:

CPU: PX6 RK3399 (Dual-core ARM Cortex-A72 1.8GHz and Quad-core ARM Cortex-A53 1.4GHz)

OS System: Android 10 (Shows Android 10 actual Android 9)

RAM: 4GB

ROM: 64GB

Carplay: Wireless and Wired

Android Auto / Hicar: Wireless and Wired

Camera: Rear / Front / Left / Right 4 CAM Input (guideline and radar)

Play Store / YouTube: Yes

Split-screen: Support

Microphone: Use original car

Steering wheel controls: Support

Support AC display on Android interface

Retaining original car functions.

Questions and Answer:
Does this android interface support connect headrest?
Yes, it have HDMI OUT. Support connect the headrest and rear seat screens.


How about the warranty of the product?
If there is any quality issue, it support 1 year for repair.

Will this android interface damage the function of my original car?
Will not damage. All factory features will keep. After install our android carplay interface, your car will have two systems, all original car functions will keep in original car system. And the installation is easy. All cables are plug and play!

Lsailt Android Carplay video interface for 2015-2020 GMC Canyon Intellilink System
