569.4V 160Ah Electric Vehicle Batteries IP65 1375*538*430mm Dimension
569.4V 160Ah Electric Vehicle Batteries IP65 1375*538*430mm Dimension
Specifications
Brand Name :
Soundon
Model Number :
SD-EV-569-160
Certification :
CE, MSDS, ROHS,UL
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Supply Ability :
50units / week
Delivery Time :
30 working days after payment
Packaging Details :
wooden package
Voltage range :
569.4V
Capacity :
160Ah
Total energy :
91kWh
Voltage Range :
468～655.2V
Energy Density :
≥140Wh/kg
Protection Level :
IP65
Dimension :
1375*538*430mm
Battery Cell :
3.65V32Ah
Description

596.4V/160AH Electric Truck Battery With High Energy Density and Capacity For Electric Heavy Truck

1


Type




NCM lithium ion battery
2

Min Configuration

5P1S
3

Single Battery Box Configuration

5P78S
4


Battery Model

EV-014-569160-01
5

Rated Voltage

569.4
6

Rated Capacity



160
7


Working Voltage Range

468~655.2
8
Total Energy
SOC working range5%～100%
10Outgoing state50%～60%
11


Temp difference Range

≤10℃
12


Cell Voltage Difference

≤20mV
13

)
Cell Capacity difference

≤600mAh
15


Charging and discharging energy

C3(Ah)Rated Capacity160Ah
17

Maximum instantaneous charging current (A) 10S

256A@25℃


Energy feedback time

18


Max Continuous

160A25℃
19

Instantaneous discharge current (A) 30S

280A@25℃


MAX

20

Continuous discharge current (A)

160A@25℃


MAX

21


Working Temp Range


Charge: 0-55℃/ discharge: -20-55℃
22


Storage Temp Range

-20-45℃(1 month,50%SOC)
-10-35℃(6 months,50%SOC)
15-35℃(12 months,50%SOC)
23


Cycle life

≥1500cycle(25℃@1C)Capacity≥80%
24

Weight

650
25

Cell quantity

780
26

(Wh/kg)
Energy Density

142
27


Insulation resistance test value

>500Ω/V
28 Working humidity15%-90%
29IP gradeIP67
30 seismic resistanceQC/T743-2006
31SafetyGB/T 31467.3
32 Cooling natural cooling
33HeatingPTC heating
34 High voltage interlockNo
35


Storage Environment Temp

-20℃~+45℃


Short term less than 1 month


Battery cell parameters

parameters
Type11217127
Voltage Range3.65V
Rate Capacity32Ah
Charge ending Voltage4.2V
Discharge ending Voltage3.0V
Cycle Life≥2000 times
Discharge Currentcontinus1C；instaneous 3C,10s
charge currentcontinus0.8C；instaneous 2C,10s
Working Temperature (charge and discharge )-10℃~50℃/-20℃~55℃
Weight≈0.545Kg
Energy Density≈220Wh/Kg
Size(H*W*T)127× 217×11(mm)


Application

569.4V 160Ah Electric Vehicle Batteries IP65 1375*538*430mm Dimension
