Rocking Piston

ZW700

Max Flow

4.3 cfm (123 lpm)

Max Pressure Level

100 psi (7 bar)

Max Vacuum Level

26.8"Hg (910 mbar)

Description

A high pressure unit that can be used on tank systems as well as in laboratories on 'rough' vacuum duties.

Specification

Model Number	ZW700D2-60/7	ZW700A57/7B	ZW700A-57/7
Open Flow	4.3 cfm (123 lpm)	4.3 cfm (123 lpm)	4.2 cfm (120 lpm)
Max Pressure	100 psi (7 bar)	100 psi (7 bar)	100 psi (7 bar)
Max Vacuum	26.8"Hg (910 mbar)	26.8"Hg (910 mbar)	26.8"Hg (910 mbar)
Current at rated load	7.5A	3.7A	3.7A
Power at rated load	830W	800W	800W
Motor Type	PSC	PSC	PSC
Voltage/Frequency	115V/60Hz	220V/50Hz	220V/50Hz
Starting Current	21A	10.5A	9.8A
Noise Level	N/A	N/A	N/A
Tank Capacity	N/A	N/A	N/A
Carton Dimensions	N/A	N/A	N/A
Net Weight	23lbs (10.5kg)	23lbs (10.5kg)	25lbs (11.5kg)
