PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
Specifications
Brand Name :
YL
Model Number :
YHS-1
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
1 set per 25 days
Delivery Time :
20-25days
Packaging Details :
1 plywood case
Speed: :
3000 cards per hour
Material :
CR80 cards 0.50-0.85 mm thick
Power :
2.5kw
Position accuracy :
±0.2mm
Stamping temperature range :
120-180 centigrade degrees (normally 140-150)
Stamping area on card surface: :
no more than 48mm in card width direction and no more than 80mm in card length direction.
Description
Smart Plastic Card Foil Machine Signature Panel Hot Stamping Machine PLC Controlled YHS-1
Automatic Card Hot Stamping Machine for hologram foil stamping and signature panel applications with PLC control system.
Product Overview
The YHS-1 Smart Plastic Card Signature Panel Hot-Stamping Machine is specifically engineered for applying anti-fake holograms and signature panels to plastic cards. This advanced system also handles gold, silver, and scratch-off foil stamping for text and patterns on card surfaces. Featuring PLC control with an intuitive human-machine interface, it delivers high-speed operation, superior stamping quality, and precise positioning accuracy.
Technical Specifications
Power Supply AC 220V, 50/60 Hz
Dimensions (L*W*H) 1200*820*1580 mm
Weight Approximately 390 kg
Control System PLC + Stepping System
Compressed Air Requirement 6 KG/cm², 30L/min
Production Speed 3000 cards per hour
Material Compatibility CR80 cards 0.50-0.85 mm thickness
Power Consumption 2.5 KW
Positioning Accuracy ±0.2 mm
Stamping Temperature Range 120-180°C (typically 140-150°C)
Maximum Stamping Area 48mm (width) * 80mm (length)
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
Key Features
  • High-quality servo motor ensures operational stability and superior stamping quality with adjustable running speed and pressing stroke
  • Adjustable stepping distance for gilding film positioning
  • PLC-controlled automation with reliable operation and automatic halt/alarm functions for card absence or system failures
  • Premium imported temperature controller for precise heat management and optimal stamping results
PLC Controlled Card Hot Foil Stamping Machine YHS-1 with 3000 Cards Per Hour and ±0.2mm Position Accuracy
Application Details
The machine is supplied without hot-stamping dies. Custom dies are manufactured according to customer specifications and drawings, enabling flexible stamping of various sizes and logos to meet specific client requirements.
