Position High Accuracy 100m/Min Semi Automatic Flute Laminator
Position High Accuracy 100m/Min Semi Automatic Flute Laminator
Position High Accuracy 100m/Min Semi Automatic Flute Laminator
Position High Accuracy 100m/Min Semi Automatic Flute Laminator
Specifications
Brand Name :
AODONG
Model Number :
AO-C
Certification :
ISO9001
Place of Origin :
CN
MOQ :
1 set
Price :
18000-25000 usd
Payment Terms :
L/C, Western Union
Supply Ability :
17 sets per month
Delivery Time :
35 days
Packaging Details :
plastic film
Automatic grade :
Automatic
Driven type :
Electric
After-sales service provided :
Online support
Type :
Laminating Machine
Application :
Food,Medical,Beverage
Condition :
New
Power :
12kw
Product name :
Flute Corruagated Cardboard Laminating Machine
Warranty :
12 months
Color :
Customer's Request
Name :
flute laminating machine
Function :
High Efficiency
Description
Automatic Flute Laminating Machine With Position High Accuracy
Main features:
1. This machine is the fourth generation product of today's push-claw automatic paper mounting machine. Its advantages such as simple operation, convenient maintenance, high speed, low noise and high precision help you win the market.
2. The main components and computer control parts of this machine are made of famous brand products from Japan and Germany to ensure the precision and service life of the products.
3.BZJ series adopts high-tech liquid level control system. The glue needed by the machine is automatically supplied, and it is equipped with a glue recycling system. The glue amount can be adjusted according to the different requirements of the paper, so that the glue is coated on the paper more evenly, thus saving glue and ensuring product quality.
4. This machine is suitable for sticking cards to corrugated paper in printing and packaging industry. When the machine runs at high speed, it can work normally on the third, fifth and seventh floors of A, C, B, D, E, F and N, and the mounted paper has good flatness and high accuracy.
Technical parameters:
model
unit
AO-1300C
AO-1450C
AO-1600C
max size of cover face (W×L)
mm
1300×1100
1450×11000
1600×11000
mix size of cover face (W×L)
mm
350×350
350×350
350×350
laminating precision
mm
≤±1.5
≤±1.50
≤±1.50
design speed
m/min
100
100
100
gross power
kw
12
12
12
outline dimension
m
12.5×2.15×2.6
12.5×2.30×2.6
12.5×2.45×2.6
total weight
T
6.8
7.2
8.0
