Specifications
Model Number :
MKSP-S630T
Product Name :
PCB & CCL SUS301H Ultra-Thin Lamination Press Plate
Place of Origin :
China
MOQ :
50pcs
Price :
Negotiable
Packaging Details :
Strong plywood package with proper soft protection material inside, suitable for long distance for sea or air transport
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Standard Sizes (L*W mm) :
1500*1295, 1300*800, 1295*787, 1295*1613, 1295*1143, 1285*750, 1280*1120mm etc
Raw Material :
Premium imported SUS301H stainless steel
Supply Ability :
10000 Square Meters per Month
Application :
Professional lamination supporting plate for PCB printed circuit boards and CCL copper clad laminates
L/W size tolerance :
±1mm
Delivery Time :
10-20 working days
Standard Thickness :
0.5mm / 1.0mm / 1.2mm ultra-thin customized gauge
Brand Name :
MK
Description
Product Overview
MKSP-S301 ultra-thin lamination press plate is manufactured with high-quality imported German and Japanese SUS301H stainless steel materials. Featuring ultra-thin design and stable, reliable lamination performance, this cost-effective solution is optimized for PCB and CCL mass production lamination processes.
The ultra-thin structural design enables more stacking layers during each lamination cycle, significantly boosting production throughput. It reduces interlayer temperature differences inside the laminator, stabilizes board thermal expansion and contraction, and eliminates copper plate wrinkling defects caused by uneven heat conduction.
Universally compatible with all mainstream lamination steel plate washing machines, this product delivers high adaptability for diverse production scenarios.
Standard Sizes
PCB Lamination Press Plate (L × W, mm)
1500×1295, 1300×800, 1295×787, 1295×1613, 1295×1143, 1295×787, 1285×750, 1280×1120, 1280×1070, 1280×970, 1270×1118, 1270×1070, 1143×660, 673×571, 660×508, 24"×28"
CCL Lamination Press Plate (L × W, mm)
1910×1270, 2210×1270, 2220×1270
Premium SUS301H Ultra-Thin Press Plate | High Productivity, Stable Lamination, Anti-Wrinkle Solution for PCB & CCL Manufacturing
Core Product Advantages
  • Raw Material: Premium imported SUS301H stainless steel (German/Japanese raw material) with high rigidity and durability
  • Standard Thickness: 0.5mm / 1.0mm / 1.2mm ultra-thin customized gauge
  • Production Optimization: Supports more lamination stacking layers to effectively improve production capacity; reduces interlayer temperature difference to stabilize board size tolerance
  • Thermal Performance: Excellent thermal conductivity and stable thermal expansion coefficient, completely solving copper plate wrinkling problems
  • Equipment Compatibility: Fully adaptable to all types of industrial lamination steel plate washing machines
  • Application Scenarios: Professional lamination supporting plate for PCB printed circuit boards and CCL copper clad laminates
  • Cost Performance: Reliable industrial-grade quality with competitive pricing and lower comprehensive production cost
Performance Parameters
Parameter SUS630T Mass-Lam Plate SUS630T Pin-lam Plate
Thickness 1.0-2.0mm 1.0-2.0mm
Width ≤1300 ≤1300
Length ≤2410 ≤2410
Thickness tolerance ±0.10 ±0.10
Surface roughness (um) Ra≤0.15 Rz≤1.5 Ra≤0.15 Rz≤1.5
Positioning hole to hole tolerance -- +/-0.10
Standard bushing slot tolerance -- +0.10/-0mm
Warpage degree ≤3mm/M ≤3mm/M
L/W size tolerance ±1mm ±1mm
Yield strength ≥1175 N/mm² ≥1175 N/mm²
Tensile strength ≥1400 N/mm² ≥1400 N/mm²
Extensibility ≥5% ≥5%
Hardness HRC 50HRC±2 50HRC±2
Work temperature ≤400℃ ≤400℃
Parallelism ≤0.03 ≤0.03
Diagonal deviation 1-2mm 1-2mm
Thermal conductivity ≥18W/MK at 300℃ ≥18W/MK at 300℃
Average thermal expansion coefficient (10⁻⁶/℃) 10~12 10~12
