120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
120mm Shipbuilding Steel Plate Galvanized Carbon Stainless Sheet Rolled
Specifications
Brand Name :
Ansteel Baostell, Wusteel
Model Number :
NM360,NM400,NM450,NM500,NM550,NM600, NM650,NR360,NR400
Certification :
ISO9001/CE/SGS
Place of Origin :
Jiangsu,China
MOQ :
5Tons
Price :
Negotiation
Payment Terms :
L/C, T/T(30% Deposit)
Supply Ability :
1000Tons per month
Delivery Time :
5-10 working days after order confirmed and receive deposit
Packaging Details :
Standard export seaworthy package or as customer required.
width :
5mm-120mm
Length :
1-12 meters
HRC :
5-120mm
Price Term :
EX-Work, FOB, CFR, CIF
Surface Treatment: :
Coated/galvanized
Technique: :
Hot Rolled/Cold Rolled
Type :
Factory wholesale ASTM A36 hot rolled steel sheet carbon steel plate
Grade: :
Q235/SS400/Q345/Q195/Q355B
Description

Production

High strength abrasion resistant steel plate is high-strength and wear-resistant steel with favourable hardness and impact toughness. With wear plate you can extend the lifespan of machinery, decrease wear in structural components and save costs.
Abrasion resistant carbon steel thicknesses range now from 8 mm up to 70 mm providing a solution to all wear needs. The plate width is from 1500mm to 3000mm.

High strength abrasion resistant steel plate is utilised in various applications of mechanical engineering by, for example, the automotive, heavy lifting and transportation, and mining industries.

Description Wear Resistant Plate
HRC 5-120mm
Related Material NM360,NM400,NM450,NM500,NM550,NM600,
NM650,NR360,NR400,B-HARD360, B-HARD400
Specifications Thickness:5mm-120mm
width :1-4 meters .
Len
gth:1-12 meters .
Price Term
EX-Work, FOB, CFR, CIF

Steel grades and chemical composition(MAX, %):

Grade C SI MN P S CR NI MO TI
NM300 0.23 0.7 1.6 0.025 0.015 0.7 0.5 0.4 0.05
NM360 0.25 0.7 1.6 0.025 0.015 0.8 0.5 0.5 0.05
NM400 0.3 0.7 1.6 0.025 0.01 1 0.7 0.5 0.05
NM450 0.35 0.7 1.7 0.02 0.01 1.1 0.8 0.55 0.05
NM500 0.38 0.7 1.7 0.02 0.01 1.2 1 0.65 0.05
NM550 0.38 0.7 1.7 0.02 0.01 1.2 1 0.7 0.05
NM600 0.45 0.7 1.9 0.02 0.01 1.5 1 0.8 0.05

Packing & Delivery

Packing Details :
Export standard package, bundled or be required.
Delibery Time:
Accroding to order quantity
Recommend Shipping Ways:
By sea(Container or Bulk)
By air or express: small size sample
Container size :
20ft GP: 5.8m(length) x 2.13m(width) x 2.18m(high)40ft GP: 11.8m(length) x 2.13m(width) x 2.18m(high)
40ft HG: 11.8m(length) x 2.13m(width) x 2.72m(high)
