Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Welded Precision Carbon Steel Tube DIN 2393 1-8mm Wall Thickness
Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Material :
St34.2,St37.2,St44.2,St52.3
Standard :
DIN 2393
Type :
Welded
OD :
6mm~65mm
Wall Thickness :
1~8mm
Application :
Hydraulic system steel tube
Surface Treatment :
Polished,brightness,metallic color
Mark :
As Required
Description

Carbon Steel Tube DIN 2393 St34.2 St44.2 Welded Precision Steel Tubes

Standard: DIN 2393 standard applies to welded precision steel tubes.

Main steel grades: St34.2,St37.2,St44.2,St52.3

Application: It is used for Auto and motorcycle shock absorber,Gas spring ,Hydraulic system steel tube,Electric industry,Construction machinery,Heat exchanger and condenser.

Grade and chemical composition:

GRADE C max Si max Mn max P max S max Al max
S34.2 0.15 0.30 0.60 0.025 0.025 D
St37.2 0.17 0.30 0.70 0.025 0.025 D
St44.2 0.21 0.30 1.10 0.025 0.025 D
St52.3 0.22 0.55 1.60 0.025 0.025 ≥0.020

Note:

The content of the microalloy element allows: Nb≤0.03%,Ti≤0.05%,V≤0.05%; Nb+Ti+V≤0.05% D. This steel can also be used for pure aluminum deoxidation Al≥0.020%.

Mark: As required.

Pipe end: Plain end, or as per customers' special request.

Finishing: Polished,brightness,metallic color.

Packing: Exporting package/wooden box /as requirement.
