Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Material :
A106 Gr.A, Gr.B, Gr.C
Type :
Seamless
OD :
NPS 1/8~NPS 48
Wall Thickness :
>=SCH10
Application :
High-Temperature Service
Surface Treatment :
Varnish, Oil-dip, Passivation, Phosphating, Shot Blasting
Delivery Status :
Annealed, normalized, normalized+Tempered, etc
Description

Boiler Seamless Carbon Steel Pipe ASTM A106 Gr. C For High Temperature Operation

A106 is only produced as a seamless product and is available in three grades; A, B, C. There are no Types in A106 because it is produced only as a seamless product.

The ASTM A106 specification is for seamless carbon steel pipe for High-Temperature Service. It covers nominal pipe sizes (NPS) 1/8” NPS to 48 NPS”. For sizes 1- 1/2” NPS and under, A106 may be produced by two different processes; either hot finished or cold drawn. Unless otherwise specified, pipe 2″ NPS and over shall be furnished hot finished. Typical uses for A106 are for handling liquids and gasses at high temperatures and pressures in power plants, oil refineries, and industrial facilities.

Product Standard: ASTM A106 Standard Specification for Seamless Carbon Steel Pipe for High-Temperature Service

Main steel grades: A,B,C

Application: Steel pipe are widely used in petroleum and chemincal industry,city construction,piping installation,etc.mechanical manufacturing,etc.

Chemical Requirements:

Grade Chemical Composition, %
C Mn P S Si Cr Cu Mo Ni V
max max max min maxC maxC maxC maxC maxC
Grade A 0.25A 0.27–0.93 0.035 0.035 0.1 0.4 0.4 0.15 0.4 0.08
Grade B 0.3B 0.29–1.06 0.035 0.035 0.1 0.4 0.4 0.15 0.4 0.08
Grade C 0.35B 0.29–1.06 0.035 0.035 0.1 0.4 0.4 0.15 0.4 0.08

Mechanical Properties:

Grade Mechanical Properties
Tensile strength, min: (Mpa)

Yield strength, min:

(Mpa)
Grade A 333 205
Grade B 415 240
Grade C 485 275

Mark: As required.

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

End: plain end, beveled end, threaded

End protection: plastic caps

Surface treatment: oil impregnation, paint, passivation, phosphating, shot blasting etc.

Packing: Exporting package/wooden box /as requirement.
