A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
A333 Gr9 Seamless Carbon Steel Tube For Low Temperature Pressure Vessel
Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Material :
A333Gr1, Gr3, Gr4, Gr6,Gr7,09Mn2VDG...
Standard :
A333 / SA333，GB/T18984-2003
Type :
Seamless
OD :
8mm~1200mm
Wall Thickness :
0.8mm~200mm Cryogenic equipment
Application :
Cryogenic equipment
Surface Treatment :
Varnish, Oil-dip, Passivation, Phosphating, Shot Blasting
Delivery Status :
Annealed, normalized, normalized+Tempered, etc
Description

A333 Gr9 Seamless Carbon Steel Industrial Tube For Low-Temperature Pressure Vessel and Heat Exchanger Pipe 141.3 * 15.88mm

ASTM A333 Grade 9 Standard covers seamless and welded steel pipe for low temperature service. The ASTM A333 Grade 9 steel involved is similar to AISI 4032 low alloy steel. ASTM A333 Grade 9 pipe shall be made by the seamless or welding process with the addition of no filler metal in the welding operation. ASTM A333 Grade 9 covers seamless and welded steel pipe for low temperature service. The Grade 9 alloy steel involved is similar to AISI 4032 low alloy steel.

Product Standard: GB/T18984-2003,ASTM A333,ASME SA333
Main steel grades: 16MnDG,10MnDG,09DG,09Mn2VDG,06Ni3MoDG,ASTM A333Gr1,A333Gr3,A333Gr4,A333Gr6,A333Gr7,A333G8,A333Gr9,A333Gr10,A333Gr11

Application: for low temperature pressure vessel pipes of -45 °C ~ -195 °C and low temperature heat exchanger pipes.

Chemical Requirements & Mechanical Properties:

Standard GB/T18984-2003
Chemical Components (%)
Grades C Si Mn P S Cr Ni Cu Mo V Al
16MnDG 0.12-0.20 0.20-0.55 1.20-1.60 ≤0.025 ≤0.025 -- -- -- -- -- --
10MnDG ≤0.13 0.17-0.37 ≤1.35 ≤0.025 ≤0.025 -- -- -- -- ≤0.07 --
09DG ≤0.12 0.17-0.37 ≤0.95 ≤0.025 ≤0.025 -- -- -- -- ≤0.07 --
09Mn2VDG ≤0.12 0.17-0.37 ≤1.85 ≤0.025 ≤0.025 -- -- -- -- ≤0.12 --
06Ni3MoDG ≤0.08 0.17-0.37 ≤0.85 ≤0.025 ≤0.025 -- 2.5-3.7 -- 0.15-0.30 ≤0.05 --
ASTM A333 A333Gr1 ≤0.30 -- 0.40-1.06 ≤0.025 ≤0.025 -- -- -- -- --
A333Gr3 ≤0.19 0.18-0.37 0.31-0.64 ≤0.025 ≤0.025 -- 3.18-3.82 -- -- -- --
A333Gr4 ≤0.12 0.18-0.37 0.50-1.05 ≤0.025 ≤0.025 0.44-1.01 0.47-0.98 0.40-0.75 -- -- 0.04-0.30
A333Gr6 ≤0.30 ≥0.10 0.29-1.06 ≤0.025 ≤0.025 -- -- -- -- -- --
A333Gr7 ≤0.19 0.13-0.32 ≤0.90 ≤0.025 ≤0.025 -- 2.03-2.57 -- -- -- --
A333Gr8 ≤0.13 0.13-0.32 ≤0.90 ≤0.025 ≤0.025 -- 8.40-9.60 -- -- -- --
A333Gr9 ≤0.20 -- 0.40-1.06 ≤0.025 ≤0.025 -- 1.60-2.24 0.75-1.25 -- -- --
A333Gr10 ≤0.20 0.10-0.35 1.15-1.50 ≤0.030 ≤0.015 ≤0.15 ≤0.25 ≤0.015 ≤0.50 ≤0.12 ≤0.06
A333Gr11 ≤0.10 ≤0.035 ≤0.60 ≤0.025 ≤0.025 ≤0.50 35.0-37.0 -- ≤0.50 -- --

Standard Grades TS(Mpa) YS(Mpa) Elongation(%)
vertical horizontal

GB/T1898

-2003

 16MnDG 490-665 ≥325 ≥30 --
10MnDG ≥400 ≥240 ≥35 --
09DG ≥385 ≥210 ≥35 --
09Mn2VDG ≥450 ≥300 ≥30 --
06Ni3MoDG ≥455 ≥250 ≥30 --
ASTM A333 A333Gr1 ≥380 ≥205 ≥35 ≥25
A333Gr3 ≥450 ≥240 ≥30 ≥20
A333Gr4 ≥415 ≥240 ≥30 ≥16.5
A333Gr6 ≥415 ≥240 ≥30 ≥16.5
A333Gr7 ≥450 ≥240 ≥30 ≥22
A333Gr8 ≥690 ≥515 ≥22 --
A333Gr9 ≥435 ≥315 ≥28 --
A333Gr10 ≥550 ≥450 ≥22 --
A333Gr11 ≥450 ≥240 ≥18 --

Heat Treatment Requirements:

All seamless and welded pipe shall be treated to control their microstructure by the following methods: Normalizing per A 333/A 333M-05 section 4.2.1.1; section 4.2.1.2 or section 4.2.1.3 Quenched and Tempered per A 333/A 333M – 05 section 4.2.2.1 Double Normalized and Tempered per A 333/A 333M – 05 section 4.2.2.2

Mark: As required.

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

Surface treatment: oil impregnation, paint, passivation, phosphating, shot blasting etc.

Packing: Exporting package/wooden box /as requirement.
