Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Material :
STB340, STB410, STB510
Standard :
JIS G3461
OD :
19.05 ~ 168.3mm
Wall Thickness :
2.0~14mm
Application :
Boiler Tube
Mark :
As requirement
Description

JIS G3461 STB340 Carbon Steel Tubes For Boiler OD 19.05mm ~ 168.3mm

Standard: JIS G3461

Main steel grades: STB340, STB410, STB510

Application: JIS G3461 steel tube can be widely used as boiler water tube, smoke tube, superheater tube, air preheating tube, accessories for transferring heat inside and outside the pipe.

Chemical Requirements & Mechanical Proterties:

Standard Grades Chemical composition
C Si Mn P S Cr Mo Cu Ni V
JIS G3461 STB340 ≤0.18 ≤0.35 0.30～0.60 ≤0.035 ≤0.035 / / / / /
STB410 ≤0.32 ≤0.35 0.30～0.80 ≤0.035 ≤0.035 / / / / /
STB510 ≤0.25 ≤0.35 1.00～1.50 ≤0.035 ≤0.035 / / / / /

Standard Grades

Tensile strength

(MPa)

Tensile strength

(MPa)

 Elongation (%)
JIS G3461 STB340 ≥340 ≥175 ≥35
STB410 ≥410 ≥255 ≥25
STB510 ≥510 ≥295 ≥25


Mark: As required.

Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.

Delivery status: Annealed, normalized, normalized+Tempered, etc.

End: plain end, beveled end, threaded

End protection: plastic caps

Outside coating: black painting, anti-corrosion oil,galvanized finish, finish as per customer requirements.

Packing: Exporting package/wooden box /as requirement.
