Specifications
Brand Name :
Y&G
MOQ :
Negotiation
Price :
Negotiable
Supply Ability :
2000t per month
Delivery Time :
30days
Packaging Details :
In pallets, wooden cases or weave strips as required.
Material :
Metal.plastic
Size :
Customzied
Hole Shape :
Round ,rectangular,square, oval etc.
Usage :
gas-liquid filters, Gas Filter etc.
Application :
Chemical Industry.
Advantages :
Excellent Filtration Performance
Description

Wire Mesh Demister Column Internals With Excellent Filtration Performance

Wire mesh demisters are widely used when a effective separation between liquid and solid phase is very important in order to obtain cheap and efficient industrial processes.
This kind of separators are made by a alveolar structure of wire mesh obtained by the superposition of several layers of a tubular sock. This sock is weaved by very thin wires (usually with a diameter inferior to 0,3 mm) and that allows to obtain a structure with high free volume (usually > 95%), a big active surface with a low density of the mesh allowing a saving about used material and costs.

Specification of Mist Eliminator, Demister Pad
(1) Standard Type

Wire Diameter
dw(mm)

Width Tolerance
(mm)

Density
ρ(kg/m3)

Surface Area
α (m2/m3)

Void Fraction
ε
Flat Wire Round Wire ±20 150 Flat Wire Round Wire 0.981
0.1*0.4 0.23 475 320


(2) High Penetration

Wire Diameter
dw(mm)

Width Tolerance
(mm)

Density
ρ(kg/m3)

Surface Area
α(m2/m3)

Void Fraction
ε
Flat Wire Round Wire ±20 98 Flat Wire Round Wire 0.9875
0.1*0.4 0.23 313 217


(3) High Efficiency

Wire Diameter
dw(mm)

Width Tolerance
(mm)

Density
ρ(kg/m3)

Surface Area
α(m2/m3)

Void Fraction
ε
Flat Wire Round Wire ±20 182 Flat Wire Round Wire 0.977
0.1*0.28 0.19 626 484


Application:
- to purify gasses;
- to eliminate liquids that could damage the production processes;
- to prevent problems to the plant structures;
- to prevent dangerous emissions for the environment;
- to recover expensive liquids
