Specifications
Brand Name :
Y & G
MOQ :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
8000MT/Month
Delivery Time :
25-35 days
Packaging Details :
Exporting package/wooden box / per customers’ requirement
Price :
Negotiable
Material :
E75,S-135
Standard :
API SPEC 5D,API SPEC 5DP
OD :
60.3-139.7mm
Wall Thickness :
7.11-10.54mm
Application :
For well drilling
Package :
Exporting package/ per customers’requirement
Description

API SPEC 5D Drill Pipe Casing For Mining , Steel Line Pipe 4" - 8 "

DrillPipe

A connecting rod used to transmit power in a drilling tool. The usual components of the drill string are: drill bits, drill collars, drill rods, stabilizers, special joints, and square drill rods. The basic function of the drill string is:(1) start the drill bit; (2) Pressing drilling pressure; (3) Transmission of power; (4) Transmission of drilling fluid; (5) Special operations: squeezing cement, handling underground accidents, etc..

Standard : API SPEC 5DP, API SPEC 5D, GB 4775-1984, SY/T 5561-2014

Grade: E -75, X -95, G-105 and S-135,DZ40 DZ50 DZ60 R780

Size:

Size Designation Calculated Weight Calculated Weight Grade Wall Thickness Upset End,for
Weld-on Tool
Joints(see Note)
in mm lb/ft kg/m in mm
2 3/8 ″ 60.3 6.65 6.26 9.32 E.X.G.S 0.280 7.11 EU
2 7/8 ″ 73.0 10.40 9.72 14.48 E.X.G.S 0.362 9.19 EU
3 1/2 ″ 88.9 13.30 12.31 18.34 E.X.G.S 0.368 9.35 EU
3 1/2 ″ 88.9 15.50 14.63 21.79 E.X.G.S 0.449 11.40 EU
4 ″ 101.6 14.00 12.93 19.26 E.X.G.S 0.330 8.38 EU
4 1/2 ″ 114.3 16.60 14.98 22.31 E.X.G.S 0.337 8.56 EU
4 1/2 ″ 114.3 20.00 18.69 27.84 E.X.G.S 0.430 10.92 EU
5 ″ 127 19.50 17.93 26.71 E.X.G.S 0.362 9.19 IEU
5 ″ 127 25.60 24.03 35.79 E.X.G.S 0.500 12.70 IEU
5 1/2 ″ 139.7 21.90 19.81 29.51 E.X.G.S 0.361 9.17 IEU
5 1/2 ″ 139.7 24.70 22.54 33.57 E.X.G.S 0.415 10.54 IEU

Note: EU-External Upset IEU-Internal & External Upset IU-Internal Upset

Application: For well drilling

API SPEC 5D Drill Steel Line Pipe Casing For Well Drilling And Mining
