Specifications
Brand Name :
Tanku
Model Number :
OEM
Certification :
SGS, ROHS
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
1500pcs month
Delivery Time :
7 working days after receiving Order Pay
Packaging Details :
Normal Corrugated Carton Packing for International Shipment
Product Name :
Roll Wrapped Carbon Pipe
Size :
100MM OD x 96MM ID 500MM Long
Material :
100% real carbon fiber composite, T300 carbon fibers
Technique :
Roll-Wrapped/Pultrusion
Color :
Black/White/Red/Blue/Customized
Surface Treatment :
Polished/Matt/Sandblasted
Tolerance :
±0.1mm
Description

100MM OD x 96MM ID 500MM Long 3K Twill Matte Carbon Fiber Tube Roll Wrapped Carbon Pipe

This 100MM OD x 96MM ID x 500MM Long Carbon Fiber Tube is manufactured using a premium roll-wrapped process and high-strength 3K carbon fiber fabric, delivering exceptional rigidity, lightweight performance, and dimensional accuracy. Featuring a sophisticated 3K twill matte finish, the tube offers both superior mechanical properties and an attractive carbon fiber appearance suitable for professional engineering and industrial applications.

The roll-wrapped manufacturing method allows multiple layers of carbon fiber to be precisely oriented around a mandrel, producing a tube with excellent strength, stiffness, and resistance to bending and torsional loads. With a 100mm outer diameter, 96mm inner diameter, and 2mm wall thickness, this carbon fiber pipe provides an ideal balance between lightweight construction and structural integrity.

Compared with aluminum or steel tubing of similar dimensions, this carbon fiber tube significantly reduces weight while maintaining outstanding load-bearing capability. The composite structure is highly resistant to corrosion, moisture, chemicals, UV exposure, and fatigue, ensuring reliable long-term performance in demanding environments.

The matte surface finish reduces glare and provides a modern, professional appearance, making the tube suitable for both structural and visible applications. Precision manufacturing ensures smooth surfaces, consistent wall thickness, and excellent dimensional stability for easy integration into custom assemblies and high-performance systems.

Applications

  • UAV, drone, and multicopter airframes
  • RC aircraft, helicopters, boats, and racing vehicles
  • Robotics and automation equipment
  • Aerospace and aviation structural assemblies
  • Automotive lightweight reinforcement components
  • Marine structures and boating accessories
  • Camera sliders, tripods, stabilizers, and filming equipment
  • Sporting goods such as bicycle components, archery equipment, and outdoor gear
  • Medical and scientific instrumentation
  • Industrial machinery and automation systems
  • Laboratory equipment and testing devices
  • Custom engineering projects and product prototyping
  • DIY fabrication and maker projects
  • Architectural and display structures

Technical Specifications

  • Material: 100% Carbon Fiber Tube
  • Weave Style: 3K Twill Weave
  • Shape: Round Tube
  • Color: Carbon Fiber Black
  • Manufacturing Method: Roll Wrapped / Pultruded
  • Length: Standard or Customized
  • Outer Diameter: Multiple Sizes Available
  • Inner Diameter: Customized According to Requirements
  • Wall Thickness: Various Options Available
  • Temperature Resistance: Suitable for a wide range of operating environments
  • Corrosion Resistance: Excellent
  • Weather Resistance: Excellent
Material Carbon Fibre Tube
Shape Round
Technology Roll-wrapped or pultrusion
Dimension The existing inner diameter of the mold is 4mm-50mm with a length of 1m.
Customizable size: The maximum diameter can be 200mm, the longest can be 3m.
Surface Black glossy/matte surface/painted
Glossy 3k weave/matte 3k weave
Color metal wire weave
Feature lightweight, high strength
Working Temperature Usually, -30-120 degrees, if special requirement, please let us know.
Place Of Origin China
Function Marine, Agriculture Tools, Arrow Shaft, Medical, Sport Products
Tolerance Diameter Tolerance: +/-0.1mm
Length Tolerance +/-1mm
