Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes
Specifications
Brand Name :
SUPAL
Place of Origin :
Changzhou,Jiangsu,China
MOQ :
5PCS
Payment Terms :
T/T
Supply Ability :
10000000PCS
Delivery Time :
7-15Days
Packaging Details :
1.One piece in a platic pipe, 10 pieces per group. 2.Use the air bubble paper to encase the plastic pipe. 3.Put the goods encased with air bubble paper in the carton. 4.Other packing will be accept according to your needs.
Model Number :
OEM
Product name :
End Mill
Coating :
AlTiN, TiAIN, TiCN, TiN, TiAlN
Diameter :
0.2-20mm
Material :
Tungsten steel
Overall Length :
50mm-200mm
Design :
Square,Ballnose,cornor radius
Price :
To be negotiated
Description

HRC55 Square CNC Solid Tungsten Carbide Fresa End Mill Cutter For Milling

Product Name
Extra Long 2 Flutes HRC55 Square CNC Solid Tungsten Carbide Fresa End Mill Cutter For Milling
Workpiece Material
Carbon Steel/ Alloy Steel/ Grey Cast Iron/ High-Alloy Cast Iron
Application
Side Face/ Step Shoulder/ Straight Slot /Deep Slot
Sample
Yes
Type
Flattened
Stock
Yes
Raw Material
Carbide
OEM/ODM
Yes
Grain of Powder
0.5μm
Tolerance
±0.01
Helix Angle
35°
Flutes
2F
Coating
AlCrSiN
HRC
HRC55
Coating Color
Bronze

Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes

Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes

Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes

Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes

Product Parameters:

HRC45 HRC55 HRC60 HRC65
YG10X YG10.2&WF25(TaiWan) K44&K40(Germany) H10F(Sweden)
Grain Size:0.7um Grain Size:0.6um Grain Size:0.5um Grain Size:0.5um
Co:10% Co:10% Co:12% Co:10%
Flexural strength:3320N/mm2 Flexural strength:4000N/mm2 Flexural strength:4300N/mm2 Flexural strength:4300N/mm2

Coating:

Item AlTiN TiAIN TiSiN nACo
Hardness(HV) 3200 2800 3600 42(GPA)
Thickness(UM) 2.5-3 2.5-3 3 3
Oxidation temp(°) 900 800 1000 1200
Friction coefficient 0.3 0.3 0.45 0.4
Color Black Violet Copper Blue


Long Flute/Shank Carbide End Mill For Steel Machining Fraises Plates Customized Sizes

Inclined oil hole machining

Convex milling: Solid carbide four flutes flattened endmill with straight shank,

high stability edge treatment and high-rigidity structure design can realize multiple-functions of machining.
Inclined oil hole-making: combined with special coating grade, optimized structure design can achieve high-efficiency drilling machining.

AL series endmills, with shape cutting edge and large helical angle design, can effectively prevent built-ups from occurring.

Impact-resistance design on whole edges can achieve high surface quality.
