Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Specifications
Brand Name :
SANYING
Model Number :
C21
Place of Origin :
China
MOQ :
1
Price :
To be discussed
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
100 sets/month
Delivery Time :
25days
Packaging Details :
Standard export packaging
Product_Name :
Tire Alignment Machine
Measurement :
fully electronic
Features :
reliable,stable,easy to operate
Pressure Gauge :
0-12kg/cm2
Car Fitment :
Abarth
Automatic :
yes
Power Source :
Electric
Working Way :
independent or with wheel aligner
Power Supply :
220v
Target Quantity :
4PCS
Description
Truck Wheel Alignment Machine - Camera-Based Commercial Wheel Axle Alignment System
Advanced 2.4GHz Bluetooth wireless transmission technology for bus and commercial vehicle wheel alignment equipment.
Truck Wheel Alignment Machine Camera based commercial wheel axle alignment system 2.4GHz Bluetooth wireless transmission technology Bus Wheel Alignment Equipment
Testing Capabilities
Single toe-in, total toe-in, camber angle, caster angle, steering synchronization, axle deflection, axle parallelism, maximum steering angle, steering forward spread, ball head clearance, thrust angle, and more.
Product Features
  • Advanced camera measurement mode with complete functions and simple operation
  • Embedded computer system running independent Linux OS and underlying software
  • Highly integrated camera sensor assembly with data processing capabilities and high-precision infrared fill lights
  • Wave-shaped measurement target with multiple target surfaces for different working conditions
  • Dual wheel compensation functions: rolling compensation and manual compensation
  • 3D modeling based on vehicle frame geometric centerline for accurate measurements
  • Comprehensive parameter measurement including toe-in, camber, steering synchronization, and axle deflection
  • WIFI communication with stable performance, low power consumption, and long-distance transmission
  • Resistant to temperature changes, magnetic field interference, and strong light interference
  • Camera sensor assembly provides up to twelve hours continuous operation
  • Multiple professional wheel rim adapters for different user requirements
  • 65W fast charging with approximately 1-hour charging time
  • Camera self-calibration function with strong working condition adaptability
  • Core components constructed from 7-series magnesium aluminum alloy
  • Centralized measurement process using complete computer system for fast, efficient operation
  • Miniaturized components with bump resistance for convenient mobile operation
Measurement Principle
The Sanying camera-based commercial wheel axle positioning system utilizes image recognition technology with patented photography methods. Using the vehicle frame centerline as reference, it measures wheel bridge positioning angles for trucks, buses, tire service centers, and commercial vehicle repair companies, providing fast and accurate wheel bridge positioning solutions.
Dynamic Detection & Adjustment
Features dynamic real-time detection and adjustment functions. Easy operation with wheel hub adapters that accommodate all tire clamping requirements within 245/70R19.5-315/60R22.5 range. Single wheel inspection time under 5 seconds, double rear axle vehicle inspection under 15 minutes. Adjustment results dynamically displayed on screen with clear pass/fail indicators for operator identification.
Measurement Parameters
Measurement Items Measurement Range Measurement Accuracy
Total Toe ±20° ±2°
Single Toe ±10° ±1°
Camber ±20° ±2°
Caster ±20° ±2°
Dip Angle ±5° ±2°
Maximum Steering Angle ±65° ±3°
Steering Synchronization ±10° ±4°
Vehicle Axle Deviation ±5° ±2′
