Tunnel Car Washing Machine TP-701
Tunnel Car Washing Machine TP-701
Tunnel Car Washing Machine TP-701
Tunnel Car Washing Machine TP-701
Specifications
Place of Origin :
Beijing
Brand Name :
TEPO-AUTO
Certification :
CE,ISO9001
Model Number :
TP-701
MOQ :
One Sets
Packaging Details :
Wood Package
Delivery Time :
30 days
Payment Terms :
T/T, L/C
Description

Tunnel Car Washing Machine TP-701

Breif introduction of TEPO-AUTO- TP-701

All the frame of TEPO-AUTO Tnnel Car Wash machine are designed by house type structure , without construing

the house additionally by the clients .

The whole frame are made of standard steel and it has been processed strict anti-corrosive treatment

such as acid etch,galvanization ,sandblast etc. Further more it can guarantee the good appearance as well as a life span up to 15 years.

All the driving wheel which are of wear proof are made of nylon material , with a life span at least 15 years ,it is superior to all steel material and applied to Tunnel series Car wash conveyor .

The transmission gear of the TEPO-AUTO tunnel Car Wash have the signal and drive transmission function .It is equipped with the water-proof signal transmission gear to make the work accurate and correct. The horizontal brushes structure is firstly used in car washing area , with many advantages such as work stability , accurate signal transmission etc .

Tunnel Car Washing Machine TP-701

Applicable Motorcycle Type

It is suitable for the cleaning, waxing, air drying, and hub cleaning of box cars such as limousine, jeep, and microbus, and those vehicle at 2.1m below . It can be equipped with chassis cleaning and highpressure water spray system .

Tunnel Car Washing Machine TP-701

Technical Parameter Of TEPO-AUTO TP-701 And Relative Tepo-Autos

MODEL

TP-500

TP-701

TP-901

TP-902

TP-1201

DIMENSIONS

( L ) ×(W ) × ( H )

800×380×300

cm

( L ×)( W) × ( H )

1000×380×300

cm

( L ) ×(W) × ( H )

1100×370×300

cm

( L) ×(W) × (H)

1300×380×300

cm

( L) × (W) ×(H)

1400×380×300

cm

CAPACI TY

550×225×210cm

550×225×210cm

550×225×210cm

550×225×210cm

550×225×210cm

CONVEYOR.LENGH

850cm

1080cm

1180cm

1380cm

1500cm

OPERATION AREA

1100×400cm

1200×400cm

1200×400cm

1500×400cm

1550×400cm

ELECTRICITY

380V/3 PHAXE

380V/3 PHAXE

380V/3 PHAXE

380V/3 PHAXE

380V/3 PHAXE

POWER

11Kw

23.5Kw

25Kw

36Kw

27Kw

WATER SUPPLY

4.5cm 2 X

4.5cm 2 X

4.5cm 2 X

4.5cm 2 X

4.5cm 2 X

WATER CONSUMPTION

90Kg/Piece

(Nonrecoverable)

15Kg/Piece(Recoverable)

90Kg/Piece

(Nonrecoverable)

15Kg/Piece(Recoverable)

90Kg/Piece

(Nonrecoverable)

15Kg/Piece(Recoverable)

90Kg/Piece

(Nonrecoverable)

15Kg/Piece(Recoverable)

90Kg/Piece

(Nonrecoverable)

15Kg/Piece(Recoverable)

WASH SPEED

45 Pieces/Hour

45 Pieces/Hour

45 Pieces/Hour

45 Pieces/Hour

45 Pieces/Hour

LONG SIDE BRUSH

4 X PCS

4 X PCS

4 X PCS

4 X PCS

4 X PCS

SHORTSIDEBRUSH

2 X PCS

4 X PCS

4 X PCS

4 X PCS

ROOF BFUSH

1 X PCS

1 X PCS

1 X PCS

1 X PCS

1X PCS

DRY BLOWER

1 SET

1 SET

2 SETS

1SET

WHEEL BRUSH

Optional

Optional

Optional

Optional

Optional

DRYBLOWERSYSTEM

Optional

Optional

Optional

Optional

1SET

HIGHPRESSURE

WET KNIFE

Optional

Optional

Optional

Optional

Optional

CHASSIS WASHER

Optional

Optional

Optional

Optional

Optional
