Specifications
Place of Origin :
China
Lens Angle :
150-degree wide-angle
Model Number :
L9MAX
Image Sensor :
Front: 8Mega Pixels, Rear: 2Mega Pixels
Price :
US$75
Packaging Details :
Color box
Rear Sensor :
Ethernet Sony IMX 335
Supply Ability :
10000
Name :
No Screen Dash Cam
Payment Terms :
T/T
WIFI :
2.4G OR 5G
Delivery Time :
30-40 days
Brand Name :
ODM/OEM
Certification :
CE & Rohs
Video Resolution :
4K+2K
MOQ :
1000
Front Sensor :
Sony IMX 415
Description
Hidden Installation Dual Lens 4K DVR with WIFI GPS Car Road Recorder
Technical Specifications
ChipsetNTK96670
SensorFront Sony IMX415 + Rear Ethernet IMX335
DisplayNo
LensFront: 150-degree wide-angle, F1.6, 6G+IR
Rear: 120-degree wide-angle, F2.0, 4G+IR
Image SensorFront: 8Mega Pixels
Rear: 2Mega Pixels
Video ResolutionFront: Real 4K (3840*2160) 24fps
Rear: 2K(2560*1440)30fps
WiFi2.4G WiFi / 5G WiFi
APPViidure
GPSSupport
Parking ModeSupport, work with hardwire kit
G-sensorSupport
Loop RecordingSupport
BatterySuper capacitor
StorageMicro TF card to 256GB
InterfaceType-C / AV connector / TF card slot
Product Overview

Achieve discreet multi-angle road scene backup without occupying extra windshield space with this screen-free dual-channel vehicle archive equipment. Two independent optical modules run synchronously: forward scenes captured in native 4K definition, while rear traffic conditions are recorded at stable 2K resolution.

Adopted compact casing without onboard preview panel for neat hidden installation behind rearview mirror. Equipped with local wireless module for convenient media file backup and integrated GPS chip to log travel trajectory, moving speed and timestamps. Perfect for private sedans, SUVs and family vehicles to preserve objective front & rear road archives when unexpected road incidents occur.

Core Features
Synchronized Dual-Channel Archive: Front 4K + Rear 2K

Two optical channels operate simultaneously without frame loss. The front lens outputs native 4K high-definition visual files to capture clear road signs, vehicle outlines and pavement details during highway travel. The external rear lens delivers steady 4K visual storage to record rear vehicles and surrounding parking environments.

HDR dynamic tone balance optimizes frame contrast under strong sunshine, tunnels and dim ambient surroundings, retaining rich scene layers under diverse natural environments. Dual-angle footage supplies comprehensive reference materials for rear-end collisions and parking scrapes.

Screen-Free Compact Hidden Installation Design

No built-in preview panel greatly reduces overall body size. The streamlined mini main unit can be neatly concealed behind the factory rearview mirror, keeping a clean windshield layout without protruding components to affect interior aesthetics.

Discreet installation style avoids distracting light reflection during driving, bringing simpler visual experience inside the cabin compared with models equipped with display panels.

Built-In Local Short-Distance WiFi for File Sync

Closed local wireless signal creates short-range coverage nearby the vehicle equipment. Users connect iOS & Android smartphones via dedicated official App to preview stored road archives and transfer visual files to mobile storage conveniently.

Important note: Wireless function only supports local file browsing and download, without off-site remote scene access capability.
Integrated GPS Travel Data Logger

High-precision satellite positioning chip embeds standardized metadata into every saved archive file, including complete travel track, real-time moving speed and accurate timestamp. Synchronized geographic route data can be displayed during playback on mobile App or desktop players, serving as reliable auxiliary reference during traffic dispute settlement and insurance claim procedures.

Intelligent Impact Triggered Protected File Storage

Built-in 3-axis gravity sensing chip continuously monitors vehicle vibration and collision state. Once bumps or external impacts are detected, corresponding visual segments will be marked as protected archives and saved into independent folders.

Locked incident files cannot be automatically cleared by cyclic storage mechanism, ensuring key reference materials will never be overwritten. Normal driving archives adopt cyclic automatic storage to achieve uninterrupted full-trip archive storage.

Slim Body & Simple Vehicle Layout

Ultra-compact main unit can be fixed steadily behind rearview mirror via adhesive bracket. Matched rear lens comes with adjustable fixed support and extended wiring harness for flexible installation at rear window or above license plate.

Adapt to standard 12V passenger vehicles. Complete installation accessories are included inside package, users can finish assembly without complicated interior disassembly or professional modification.

Frequently Asked Questions
Q1: Can the camera lens angle be adjusted?
The mounting bracket is adjustable, allowing you to fine-tune the device angle according to your vehicle model. You can adjust the angle while previewing the real-time image via the dedicated mobile app.
Q2: Why won't the dashcam power on?
The dashcam requires a stable power supply to boot up. Please verify that the power connection is secure (use the original car charger included in the package). Check if the power cable connector is loose at the dashcam port. If the issue persists, contact our after-sales support team.
Q3: What should I do if the device freezes and stops recording?
Disconnect the power supply, restart the device, and check if function is restored. Try replacing the SD card with a new one, or format the existing card (compatible with CLASS 10 U1 SD cards, 8GB-256GB capacity). If the problem remains, contact customer service immediately.
Q4: Why can't the mobile phone connect to the dashcam's Wi-Fi?
  1. Check if the dashcam is powered on and its Wi-Fi function is enabled (Wi-Fi indicator light is on).
  2. Ensure the mobile phone is close to the dashcam for proper Wi-Fi signal.
  3. Verify that the mobile phone has connected to the correct Wi-Fi name of the dashcam.
  4. If connection fails repeatedly, restart both the dashcam and mobile phone, then try again.
Q5: Built-in battery inquiry
This dashcam model does not have a built-in lithium battery. It cannot power on without being connected to a car charger. Please connect the device to the vehicle's lighter port via the included car charger to activate it.
