40BPM 320kg Cap Screw Capping Machine Automatic Bottle Cap Sealing 3PH
40BPM 320kg Cap Screw Capping Machine Automatic Bottle Cap Sealing 3PH
Specifications
Brand Name :
Fair Machinery
Model Number :
FAS-140
Certification :
CE, ISO, SGS
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union. L/C
Supply Ability :
100 pcs per month
Delivery Time :
10-20 days
Packaging Details :
wooden packaged
Automatic Grade :
Automatic
Key Selling Points :
fully Automatic, High-accuracy, Easy to Operate
Application :
Food, Beverage, Commodity, MEDICAL, Chemical, Machinery $ Hardware
Bottle type :
Plastic Bottle Glass Bottle Cans
Packaging Material :
plastic, metal, Glass
Function :
Auto Feeding Screwing Pressing Caps
Capping type :
Screw Capping Locking
Capping speed :
30-60 Bottles/Min
Warranty :
1 year
Control :
PLC+ Touch Screen
Voltage :
380V 50Hz,3PH (Customized), 380V 3phase 50HZ/60HZ
After-sales Service :
video technical support, free spare parts, field installation, commmissioning and training, field maintenance and repair service, online support
Description
mineral water High Speed Automatic Bottle Capping Machine Screw Capper Equipment For Various Bottle Caps
This machine has a high speed, high qualification rate and convenient operation. The universal capping machine is designed for the diversity of the current caps. Adopting the current in-line structure, the bottles are screwed one by one in a straight line, the screw cap speed is adjustable, and the torque can be adjusted at the same time. It is convenient and quick to replace the bottle, and does not need to change the mold, which is an ideal equipment for the enterprise to realize automatic production.

It can be applied to different bottle-shaped caps in food, pharmaceutical, daily chemical, pesticide, cosmetics and other industries. The four speed control motors are used for cover, bottle clamping, conveying and capping. The machine has high degree of automation, good stability and convenient adjustment. No need for spare parts when replacing the bottle shape or cover, just adjust it on the machine ( If equipped with a cover machine, it can be automatically covered.) It can be selected according to actual needs.

Technical parameters:

Model FAS-140
Bottle height 40-290 MM
Cap size 15-60MM
Bottle diameter 35-140 MM
Capping speed (BPM) 40-60 B／Min
Power supply (VAC) 220/380V 50/60HZ
Power (KW) 1.5
Dimensions (MM) 2300x1000x1600
Net weight (KG) 320


Sample style:

40BPM 320kg Cap Screw Capping Machine Automatic Bottle Cap Sealing 3PH

40BPM 320kg Cap Screw Capping Machine Automatic Bottle Cap Sealing 3PH
