150KVA Fawde Diesel Generator
150KVA Fawde Diesel Generator
150KVA Fawde Diesel Generator
150KVA Fawde Diesel Generator
Specifications
Brand Name :
ACEPOW
Model Number :
APF-150
Certification :
CE,ISO, SASO
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiate
Payment Terms :
L/C, D/P, T/T
Supply Ability :
10000SETS/YEAR
Delivery Time :
25 DAYS
Packaging Details :
NUDE PACKING,PLYWOOD CASE
Standard configuration :
Technical documents
Output type :
AC Three Phase/ single phase
Control panel :
Air Breaker,Smartgen HGM6120 Control System
Engine :
Fawde
Type :
silent diesel generator
Genset power :
120KW/150KVA
Alternator :
AVR
Cooling method :
50℃ Radiator
Generator type :
Silence Generator Set,Silent(super Silent)or Open Gene
Description

Chinese Engine Silent Diesel Generator 150kva 120kw Fawde Diesel Generator Silent Type 3 Phase Canopy Genset​

Features :

1) Brand-new diesel engine

2) Brushless alternator,single bearing

3) Auto control panel with LCD display.

4) Engine mounted battery-charging alternator,Genset with battery charge of main supply.

5) Circuit Breaker,Exhaust Silencer.

6) Copper Radiator for 40ºC ambient temperature and double-deck cooling,with fan guard and front guard.

7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable.

Engine

* Heavy duty diesel engine

* Four stroke, water cooled

* 12V and 24V stater and charge alternator

* Cooling radiator and fan

* Maintenance free battery including ract and cable

* Flexible fuel connection hoses and manual oil sump drain valve

* Exhaust silencer

Alternator

* Brushless, single bearing, flexible disc

* Insulation class: H

* Protection class: IP23

* Self-exciting and Self-regulation

Base Frame

* Base frame including position for forklift and crane

* Integral fuel tank

* Daily fuel tank continuously supply for 8-24 hours

* Fuel tank easy to maintain and clean

* Anti-vibration pads are flexed between engine and alternator.

GENSET MODEL APX-100 APX-125 APX-150
Prime output (KVA/KW) 100/80 125/100 150/120
Standby output(KVA/KW) 110/88 138/110 165/132
Rated voltage(V) 400/230 400/230 400/230
DIESEL ENGINE MODEL 4DX23-65D CA6DF2-17D CA6DF2-19D
Rated Power(kW) 53 110 132
Cylinder numbers In-Line 4 cylinders
Method of operation 4-stroke
Govering method Mechanical
Starting system DC 24V Electronic start
Cooling method Closed water cooled
Total displacement(L) 3.86 3.86 3.86
Compression ratio 17.0:1 17.0:1 17.0:1
Bore*Stroke(mm) 102*118 102*118 102*118
Fuel consumption(L/h) 11 7 7
ALTERNATOR MODEL UC274C UC274DS UC274F
Rated Power(kW) 80 100 120
Rated frequency(Hz) 50
Rated speed(rpm) 1500
Phase connection 3-phase, 4-wire connected (12-wire for 3-phase)
Number of Bearing 1
Power Factor 0.8
Protection Grade IP23
Exciter Type Brushless, Self-Exciting
Insulation Class,
Temperature Rise		 H/H
CONTROL PANEL V-meter, A-meter, Frequecny meter, circuit breaker, transfer switch, temp. and pressure gauges, indicating lamp, hour meter, key starter, etc.
NET WET(kg/Open type) 1070 1350 1350
PACKING SIZE(mm/Open type) 1950x860x1330 2480x9300x1400 2480x9300x1400
