2.07 MP RGB Rolling 99 - Degree View Shutter Camera Module IMX291 Sensor For Biometrics , Customization Services Available .

1. Basic Parameters:

- Resolution: 1920 (H) × 1080 (V), 2.07MP, supports full HD imaging and compatible with cropped HD output simultaneously; delivers stable performance without motion blur under normal operating conditions.

- Pixel Size: 2.9μm (H) × 2.9μm (V). The large pixel photosensitive area greatly increases light intake in low-light environments, effectively reduces low-light noise and improves the purity of images captured under weak light.

- Optical Format: 1/2.8 inch. It features a compact size, fits various miniaturized modules, and is highly compatible with mainstream lenses available on the market.

- Supply Voltage: Core voltage 1.2V, interface voltage 1.8V, analog voltage 2.9V. It can operate stably under various voltage conditions to guarantee sensor reliability.

- Temperature Range: Operating temperature ranges from -30℃ to 70℃. Its wide operating temperature range enables adaptability to diverse working environments.

2. Technical Features:

- Rolling Shutter Technology: Adopts a rolling shutter design with progressive exposure, featuring low imaging noise and delicate detail restoration. It boasts high circuit integration, lower power consumption and cost, making it suitable for high-definition imaging in static and low-speed scenarios.

- Equipped with STARVIS back-illuminated sensor process, it achieves a minimum illuminance of 0.001Lux. Paired with infrared fill lights, it can capture clear images in complete darkness. Unlike ordinary CMOS modules that suffer from washed-out images and excessive noise at night, it restores true colors and complete details in nighttime footage, serving as a benchmark solution for starlight-level night vision imaging.

- Integrated with Exmor R back-illuminated sensor technology, it optimizes the optical path structure to reduce light refraction loss. It delivers outstanding photosensitivity for both visible light and near-infrared light bands, enabling seamless day-night imaging switching with vivid colors during the day and clean footage at night.

- IMX291 Camera Module: Compatible with standard modules fitted with various lenses including 99° lenses to meet diverse customer requirements.

3. Application Fields:

It is applied in biometric identification, drones, smart home appliances, IoT devices, machine vision, barcode scanning, factory automation and other fields.

4. Personalized Customization Service:

Custom modules can be produced on a customized basis in accordance with customer requirements to deliver tailor-made products that match clients' specific demands.
