fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
Specifications
Brand Name :
JiaMinAVTech
Model Number :
JM-1SA-3.5MM
Certification :
CE,FCC,ROHS
Place of Origin :
Shenzhen
MOQ :
5pairs
Price :
USD 55~80/pair
Payment Terms :
T/T
Supply Ability :
100000pairs/month
Delivery Time :
3~7 working days
Packaging Details :
1pair power adaptor,1 optic transmitter,1 optic receiver,1User's Manual
Connector :
3.5MM
Operating Temperature: :
-20°C ~ +75°C
Weight: :
(include Transmitter & Receiver ) 0.8kg
Power :
DC 5V@2A
Color :
black
warranty :
2years
Description

fiber optic stereo audio to 3.5mm converter also named as 1CH stereo audio fiber transmitters and receivers or 1ch stereo audio over fiber extenders,which transmit 1 or multiple stereo signals over a single / multi-mode fiber . Stereo audio source input at the transmitter end, transmitted through the optical fiber and output at the receiver side , receiver connect powered speakers or the amplifier driving the speaker, using 24bit digital audio coding system indicators to meet or exceed Class A broadcast standardSpecifications

These fiber optic transmitter and fiber optic receiver are typically used in applications for Rental, Staging, Theater, Stadiums, Theme Parks, Broadcast/Studio, CCTV audio and Professional AV applications, etc, and are available for stand-alone or rack-mount installations. FC, ST or SC optical connectors is optional.

fiber optic stereo audio to 3.5mm converter Features

• 24-Bit Digitally Encoded Audio

• Support Point-to-Point or Daisy-Chain connection

• Multimode Fiber transmit up to 4km without Optical Attenuation

• Single-Mode Fiber transmit up to 100km without Optical Attenuation

• No EMI, RFI, Cross Talk or Video Distortion and no ground loops

• LED Indicators for Instant System Monitoring

• Standalone or Rack Mount in FVC14 Chassis

• Produce according to customer's specifications, providing OEM

Specifications

Audio
Input/output Impedance 600ohm(unbalance)
Max input/output voltage 3.0Vp-p
Frequency Response 10 Hz～29kHz @±3dB
SNR > 70dB
Connector 3.5mm Stereo

Electrical & Mechanical
Input Power Requirements: DC 5V@2A
Power Adapter: AC 900V~240V
Power Consumption: < 3W
Stand-Alone Dimensions: 104mm × 104mm × 28mm
Shipping Weight: (include Transmitter & Receiver ) 0.8kg

Environmental
Operating Temperature: -20°C ~ +75°C
Storage Temperature: -40°C ~ +85°C
Relative Humidity: 0% ~ 95% (non-condensing)
MTBF: >100,000 hours

fiber optic stereo audio to 3.5mm converter Connection diagram:

fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM

dimension:

fiber optic stereo audio to 3.5mm converter for 1 ch 3.5mm broadcast stereo audio over fiber extenders to 10~120KM
