Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Male To Female High Flex Cable , Pin To Pin Soldar Type Hirose 12 Pin Cable
Specifications
Brand Name :
DHT
Model Number :
HR040-R2
Certification :
CE/ROHS/FCC/SGS
Place of Origin :
China
MOQ :
1
Price :
negotiation
Payment Terms :
T/T or western Union
Supply Ability :
300,000pcs per month
Delivery Time :
5~7days
Packaging Details :
PE
Material :
Copper
Interface Type :
Hirose
Pin :
12pin
Application :
Machine Vision
Power Cable Type :
12pin Coaxial
Feature :
Chain Flex
Computer Cable Type :
Data Transmission
Printer Cable Type :
Coaxial
4.0meters :
High Flex Chain Black
25meters :
Overmolded
Description

Flexible Hirose 12Pin Male To Female Data Cable Pin To Pin Soldar Type CCXC-12P05N

Product Description

Hirose 12Pin Male To Female Data Cable Pin To Pin Soldar Type CCXC-12P05N

The CCXC-12P05N Interconnect Cable for XC Series (16.4') is a segment of interconnect cable designed for use with Sony XC series cameras. This 16.4 ft cable features (12) pins.

Specification

The 12Pin connector is Japan original which can be molded at two ends,with high flex 5.0meter cable body,full shieding and good performance on motion system.

It has the following standard pin configuration and signal usage.

Pin 1 GND

Pin 2 +12 VDC

Pin 3 VIDEO GND

Pin 4 VIDEO OUTPUT

Pin 5 GND

Pin 6 HD SYNC INPUT

Pin 7 VD SYNC INPUT OR TRIGGER

Pin 8 GND

Pin 9 AUX SIGNAL

Pin 10 AUX SIGNAL

Pin 11 TRIGGER INPUT

Pin 12 GND

Guarantee

One-Year Warranty Against Defective Parts / Ninety-Day Warranty Covering Repairs & Labor

Part Number Compatiable

The CCXC-12P05N is a 5 meter 12-pin interconnect cable, compatible the Hitachi C501-KSM and Intercon VCP-05-S cables.
