Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Specifications
Place of Origin :
Hubei, China
Brand Name :
KAEMI or GM
Price :
$2,960.00/sets
Weight :
400 KG
Description
Retail Second Hand Flatbed Template Board Milling Cutting Machine for Garment Cutter
Product Overview
High-quality used flatbed template board milling and cutting machine designed specifically for garment cutting applications. This cost-effective solution offers professional performance at an affordable price.
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Main Features
  • Pneumatic Fixation Technology of High Efficiency Template
  • Integrated Floating Pressure Foot and Vacuum Cleaning Technology
  • Flexible Modification System for Cutting Starting Points and Cutting Sequence
  • Independent Templates Editing and Designing System
Technical Specifications
Model GM-1509M2 GM1812M3
Cutting Window (Fabric Scope) 1500×900mm 1800×1200mm
Overall Dimension (mm) 1900×1450×1100 2200×1750×1100
Product Features Compatible with various CAD softwares; Design while the machine is cutting
Cutting Speed 500-1500mm/s
Cutting Thickness ≤1.5mm-6.0mm
Cutting Materials PVC, PP, POM, Acrylic, PET, Kraft, etc
Processing Methods Mill, Cut, Drill, Plot
Cut Tools Mill-cutter, Graver, Driller, Pen
Repeatability Precision ≤0.01mm
Software Resolution 0.025mm/0.01mm/0.1mm (Optional)
Communication Port USB/RJ45 Ethernet
Buffer Memory Size 1M/8M/32M (Can buffer more than 1 page)
File Formats DXF/HPGL/GPGL/PLT Formats Compatible
Control Panel 9 Keys and LED Display
Driver System Moons Motor driver; High-accuracy Lead Rail, Double Lead Rail on crossbeam
Supply Voltage AC 220V/110V±10%, 50Hz/3.5KW
Fuse Value 30A 35A
Working Environment -30~55℃ or -22~131℉
Fasten Vacuum/Clamping
Mill Motor 800W/1500W, Water-cooling/Air-cooling, 5000~240000 RPM Inverter
Waste Elimination 220V/1.4KW, Industrial 15L Vacuum Cleaner
Product Gallery
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Packaging & Shipping
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Products are packed in sturdy wooden cases according to export standards or customer requirements.
Company Information
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Since its establishment, GEMEI has developed a comprehensive series of cutting machines for clothing, bags, shoes and hats, obtaining numerous software copyright and patent certificates. Based on profound understanding of China's garment, luggage and footwear industry, GM series cutting machines combine the essence of Chinese and foreign technologies, closely integrating world's advanced technology with Chinese manufacturing advantages.
Our design philosophy follows "good at core, simple in shape" principle. After introducing the first continuous drum cutter in central China, we successively developed specialized sample cutters for the luggage industry and continuous cutting garment sample cutters.
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
"The competition of enterprises is the competition of talents." GEMEI firmly grasps the trend of world manufacturing industry transferring to central regions, establishing a research and development team composed of doctors, senior engineers and other high-quality talents. We insist that "innovation" is the eternal driving force behind GEMEI's development.
Frequently Asked Questions
Used Flatbed Cutting Machine with 1500x900mm Cutting Scope 1.5mm-6.0mm Thickness and 500-1800mm/s Speed for Garment Template Board
Q: Are you a manufacturer?
A: Yes, we specialize in R&D and production of template cutters, inkjet cutters, pen writing cutters, CNC digital fabric cutters, and graph plotters in this field for over 10 years.
Q: How do you pack these products?
A: Usually packed in wooden cases according to export standards or your specific requirements.
Q: Is it customizable?
A: Yes, we have basic sizes commonly applied in the field and can customize according to your requirements.
Q: After-sales service
A: Yes, we provide professional after-sales team and 24-hour technical support by phone, email or Skype.
Q: What is your lead time?
A: Spot goods usually take 2-4 days, and customization takes 5-7 days.
