Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation
Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation
Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation
Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation
Specifications
Payment Terms :
T/T
Thickness :
1.0mm to 2.0mm
Supply Ability :
10000 Meters per Month
Length :
Pre Cut 2m / 3m / Custom
Certification :
ISO9001
MOQ :
Negotiable
Slot Pattern :
Open Slot
Assembly :
Bolt Coupler Joint Plates
Packaging Details :
Standard export packing
Width :
50mm to 400mm
Application :
Quick Site Cable Installation
Material :
Carbon Steel Sheet
Delivery Time :
15-30 work days
Place of Origin :
Hebei, China
Price :
Negotiable
Side Rail Height :
30mm to 150mm
Description
Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation | Expandable Open Slot Steel Trough for Fast Industrial Cable Assembly
Product Overview

The modular slotted cable tray support system is built for fast, tidy cable installation on active industrial sites. Pre cut sections, matched couplers and joint plates let crews assemble a complete run with ordinary hand tools in a short time.

This slotted cable trunking scales easily from a single machine run to a full plant network. Extra sections, bends and tees bolt onto the existing cable support tray, so the wiring layout can grow with the facility without costly rework.

Features
  • Modular Slot System Extension
    Standard sections join in any direction using couplers, bends and tees. Extra bays can be added later along the same line, letting the tray grow step by step with changing plant demand.
  • Bolt Coupler Joint Plates
    Each length ships with matching joint plates and bolts. The bolted connection locks sections into a straight, rigid run and can be undone quickly when routes need to change.
  • Factory Pre Cut Lengths
    Trays are cut to the required dimensions before dispatch. On site trimming is minimised, so installation is faster and there is less waste and fewer exposed cut edges.
  • Simple Site Handling
    Light, stackable sections and standard fasteners allow quick lifting and alignment. Handling stays easy even in tight ceiling voids and congested cable corridors.
Technical Specifications
Attribute Specification
Material Carbon Steel Sheet
Slot Pattern Open Slot
Width 50mm to 400mm
Side Rail Height 30mm to 150mm
Thickness 1.0mm to 2.0mm
Length Pre Cut 2m / 3m / Custom
Surface Treatment Electro Galvanized
Load Grade Light to Medium Duty
Assembly Bolt Coupler Joint Plates
Applications

The modular slotted cable tray support system speeds up wiring work in factories, warehouses, data centres and refurbishment projects. Fast coupler joints and pre cut sections make this expandable cable support tray and slotted cable trunking ideal where schedules are tight.

Modular Slotted Cable Tray Support System Bolt Coupler Joint Plates for Quick Site Installation
F&Q
Where is the Galvanized Cable Tray made?
Manufactured in Hebei, China
Is the Galvanized Cable Tray certified?
ISO9001 certified
What is the Minimum Order Quantity?
Negotiable based on requirements
How is pricing determined?
Custom pricing available upon request
What are delivery timelines?
15-30 work days with flexible packaging options
