Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring
Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring
Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring
Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring
Specifications
Slot Pattern :
Perforated Slot Base
Length :
3m / 6m / Custom
Certification :
ISO9001
MOQ :
Negotiable
Width :
200mm to 900mm
Price :
Negotiable
Thickness :
1.5mm to 3.0mm
Payment Terms :
T/T
Load Grade :
Medium to Heavy Duty
Place of Origin :
Hebei, China
Supply Ability :
10000 Meters per Month
Delivery Time :
15-30 work days
Application :
Plant Wide Cable Wiring
Material :
Perforated Steel Sheet
Packaging Details :
Standard export packing
Side Rail Height :
100mm to 300mm
Description
Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring | High Volume Open Slot Steel Trunking for Dense Industrial Cable Bundles
Product Overview

The large capacity multi cable slotted cable tray is designed to carry dense industrial cable bundles in one neat run. A wide perforated base and tall side rails accept several large cross section cables together with smaller branch lines.

This perforated cable support tray also works as high volume slotted cable trunking across plants, workshops and machine rooms. Regular punched openings assist airflow and let installers secure each cable group without crowding the channel.

Features
  • Large Capacity Cable Support
    Wide internal spacing holds many large diameter cables at the same time. Dense bundles stay organised in separate lanes instead of bundling tightly together.
  • Perforated Steel Slot Structure
    A perforated base lightens the tray and improves airflow around cables. The openings also provide flexible fixing points for ties, clamps and dividers.
  • Plant Wide Wiring Layout
    Long runs connect machine areas, cabinets and control rooms in one continuous route. Standard couplers keep alignment straight across the whole installation.
  • Stable Load Distribution
    Reinforced perforated side rails spread load evenly along the run. Sag is controlled so cables remain well supported over long horizontal distances.
Technical Specifications
Attribute Specification
Material Perforated Steel Sheet
Slot Pattern Perforated Slot Base
Width 200mm to 900mm
Side Rail Height 100mm to 300mm
Thickness 1.5mm to 3.0mm
Length 3m / 6m / Custom
Surface Treatment Galvanized
Load Grade Medium to Heavy Duty
Applications

Large capacity multi cable slotted trays are used for plant wide wiring, master cable routes, energy centres and heavy workshops. This perforated cable support tray keeps dense industrial cable bundles ventilated, separated and well supported over long distances.


Large Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide WiringLarge Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide WiringLarge Capacity Multi Cable Slotted Cable Tray Perforated Steel Support Tray for Plant Wide Wiring
F&Q
Where is the Galvanized Cable Tray made?
Manufactured in Hebei, China
Is the Galvanized Cable Tray certified?
ISO9001 certified
What is the Minimum Order Quantity?
Negotiable based on requirements
How is pricing determined?
Custom pricing available upon request
What are delivery timelines?
15-30 work days with flexible packaging options
