Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions
Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions
Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions
Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions
Specifications
Payment Terms :
T/T
Color :
Customizable According to Demands
MOQ :
Negotiable
Place of Origin :
Hebei, China
Delivery Time :
15-30 work days
Side Rail Height :
30 mm up to 500 mm
Material :
Carbon Steel Plate
Certification :
ISO9001
Packaging Details :
According to customer needs
Appearance :
Smooth Surface, Free of Sharp Burrs
Application :
Indoor & Outdoor Cabling Requiring Cable Barrier Protection
Width :
50mm,100mm,150mm,300mm,450mm,600mm
Price :
Negotiable
Description
Solid Base Enclosed Cable Trough in Custom Sizes | Anti-rust Trough Cable Tray for Protected Power & Signal Cable Installation

Product Overview
To sustain stable operation of power and communication systems, cables must be shielded from adverse external conditions. Our solid-base trough cable tray features non-porous bottom panel, making it different from ventilated perforated cable trays. Paired with removable matching covers, it creates a sealed routing channel to shield internal wiring against dust, humidity, sundries and mechanical friction.
The cable trough delivers comprehensive protection for power lines and signal cables, mitigating wire ageing and signal disturbance risks. Its modular splicing structure allows on-site cutting and jointing to adapt to complicated wiring paths. All hangers, connecting fittings and cover plates adopt unified specifications, simplifying field assembly and maintaining long-term reliability of the cabling system.
Features

  • Sealed Enclosed Barrier Protection
    Combination of solid base and removable cover creates an exclusive wiring channel. It blocks dust, moist air and external collision comprehensively, safeguards built-in cables and suppresses electromagnetic interference for steady power supply and signal delivery.
    Well-Organized Wiring Arrangement
    Integrated U-shaped trough body avoids cable tangling, overlapping and chaotic accumulation. It optimizes the overall project wiring layout and cuts down cross-interference between adjacent cables, elevating the safety and stability of the electrical system.
    Easy Maintenance and Wiring Upgrade
    Separable cover grants direct access to inner cables without dismantling the tray main body. Circuit checking, cable replacement and new wiring expansion can be completed rapidly, shortening construction cycles and lowering labor costs for later maintenance.
    Rich Surface Anti-Corrosion Solutions
    Available surface treatments include electro-galvanization, hot-dip galvanization and powder coating. The enclosed structure limits direct contact between corrosive media and cables, applicable to indoor equipment rooms, commercial buildings, outdoor telecom base stations and general industrial sites.

Technical Specifications
Attribute Specification
Surface Standard Smooth flat surface, all edges deburred without sharp corners
Core Feature Solid unperforated base, dustproof and moisture isolating performance
Mounting Type Wall Fixing, Ceiling Suspension, Floor Installation
Side Rail Height Adjustable Range: 30 mm ~ 500 mm
Working Environment Indoor and Outdoor Engineering Construction
Surface Finishing Electro Galvanized, Hot-dip Galvanized, Powder Spraying
Connection Method Fastened by joint plates and standard bolts
Load Class Light, Medium and Heavy Load Versions Available

The Galvanized Cable Ladder System efficiently manages and supports cables in various industries including telecommunications, power distribution, and construction. Its corrosion-resistant design makes it ideal for outdoor applications exposed to rain, snow, extreme temperatures, and corrosive environments.

Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion SolutionsCustom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions

Custom Sizes Solid Base Enclosed Cable Trough with Sealed Enclosed Barrier Protection and Rich Surface Anti-Corrosion Solutions
F&Q
Where is the Galvanized Cable Tray made?
Manufactured in Hebei, China
Is the Galvanized Cable Tray certified?
ISO9001 certified
What is the Minimum Order Quantity?
Negotiable based on requirements
How is pricing determined?
Custom pricing available upon request
What are delivery timelines?
15-30 work days with flexible packaging options
