China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine
Specifications
Brand Name :
Beyde
Model Number :
630/1+6
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
200 set/year
Delivery Time :
90 days
Packaging Details :
Safety container packing
Usage :
Stranding
Color :
According to customer requirement
Name :
Tubular stranding machine
Application :
steel,aluminium,stranding steel wire,ACSR and AAAC
Function :
Stranding Wires
Machine central height :
700mm
Central pay-off bobbin :
PN400-PN630
Take-up bobbin size :
PND800-PND1600
Plc :
Siemens
Maximum bare wire diameter :
5mm
Warranty :
12 Months
Description

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.


Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.

The 630 1+6 Tubular Electric Cable Stranding Machine is a key piece of equipment for manufacturing 7-core (1+6) stranded conductors like ACSR, AAAC, copper, and aluminum. Below is a technical overview and the typical support an engineer can expect.

Machine Overview & Key Parameters
Type: 630 1+6 Tubular Stranding Machine
Application: Stranding 7-core (1+6) conductors such as ACSR, AAAC, copper, and aluminum.
Structure: The 6-bobbin stranding cage rotates, while the central wire remains stationary, suitable for medium and large-section stranded conductors.

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

Engineering Support Areas

Pre-Sales & Basic Engineering

Application Review: Confirming suitability for the conductor type and size.

Layout & Utility Design: Providing GA drawings and calculating power, air, and foundation needs.

Process Consultation: Advising on lay length, speed, and tension ranges .

Commissioning & Training

On-site Installation: Mechanical and electrical setup, alignment, and safety checks.

Trial Runs: Assisting with startup, optimization, and first-article approval.

Operator Training: Covering operation, basic maintenance, and troubleshooting .

Remote & Field Support

Remote Assistance: Diagnosing issues via phone, video, or remote desktop.

Spare Parts: Supplying critical components like bearings, belts, and sensors.

On-site Service: Sending engineers for complex faults or modernization projects .

Maintenance & Optimization

Preventive Maintenance: Creating schedules and checklists for bearings, lubrication, and tension systems.

Upgrades: Advising on control system updates, data integration, and efficiency improvements .

Documentation & Standards

Machine Manuals: For operation, electrical schematics, and parts lists.

Process Documents: Recommended settings and quality checklists for specific conductor types.

Standards: Compliance with IEC, ISO, and regional cable standards (e.g., for ACSR/AAAC)

MODEL
DIAMETER BEFORE STRANDING [mm]
ROTARY SPEED [RPM]
CAPSTAN DIAMETER [mm]
GJ-6/160
0.12-0.40
2200
2*250
GJ-12/160
0.12-0.4
2100
2*250
GJ-18/160
0.12-0.40
1900
2*250
GJ-12/200
0.3-0.90
1500
2*320
GJ-18/200
0.3-0.90
1400
2*320
GJ-24/200
0.3-0.90
1300
2*400
GJ-30/200
0.3-0.90
1200
2*600
GJ-36/200
0.3-0.90
1100
2*600
GJ-12/250
0.4-1.0
1400
2*400
GJ-18/250
0.4-1.0
1200
2*600
GJ-24/250
0.4-1.0
1200
2*600
GJ-30/250
0.4-1.0
1100
2*600
GJ-36/250
0.4-1.0
1100
2*600
GJ-12/300
0.5-1.3
1200
2*600
GJ-18/300
0.5-1.3
1200
2*600
GJ-24/300
0.5-1.3
1000
2*800
GJ-30/300
0.5-1.3
1000
2*800
GJ-36/300
0.5-1.3
900
2*800
GJ-12/400
0.8-2.5
700
2*1000
GJ-18/400
0.8-2.5
600
2*1000
GJ-24/400
0.5-2.5
600
2*1000
GJ-12/500
1.0-3.5
650
2*1200
GJ-18/500
1.0-3.5
500
2*1200
GJ-12/630
1.5-5.0
450
2*1400
GJ-18/630
1.5-5.0
400
2*1600
GJ-12/800
2.0-6.0
350
2*1600
GJ-24/800
2.0-6.0
300
2*1800
GJ-6/1000
3.0-18.0
300
2*2000
GJ-8/1000
3.0-18.0
300
2*2000
