Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable
Specifications
Brand Name :
Beyde
Model Number :
500 1+6
Place of Origin :
China
MOQ :
1 set
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
200 set/year
Delivery Time :
90 days
Packaging Details :
container
Usage :
Stranding
Color :
According to customer requirement
Name :
Tubular stranding machine,Copper Aluminum Steel Wire Tubular Stranding Machine
Application :
steel,aluminium,stranding steel wire,ACSR and AAAC,Al wire
Wire material :
Steel,Copper,Aluminum
Function :
Stranding Wires
Taping head pitch :
7mm-2004mm
Machine central height :
1000mm
Central pay-off bobbin :
PN400-PN630
Take-up bobbin size :
PND800-PND1600
Plc :
Siemens
Warranty :
12 Months
Description

High Quality Tubular Type Cabling Machine GJJ500/1+6 For AAAC Cable

This Strander is used for making 7 or 19 Wire Strands of round, sector, compact conductor to be used in Cable Industry or for Over Head Conductors. For Wire Rope Industry we offer 6, 12, 18, 24, 36 Bay Configurations. All Tubular Stranders are with Big Encircled Bearings ensuring Higher Speeds and Long Life of the Machine.

Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable

Cabling Plc Tubular Stranding Machine GJJ500/1+6 For AAAC Cable

Model unit RLB-50 RLB-56 RLB-63
7B 12B 7B 12B 7B 12B
Pay Off Ø mm 500 500 560 560 630 630
Take Up Ø Mm 1250 1250 1600 1600 1800 1800
Copper Wire Ø Mm 0.8-3.2 0.8-3.2 1.0-3.6 1.0-3.6 1.2-4.0 1.2-4.0
Aluminum Wire Ø Mm 1.2-4.0 1.2-4.0 1.4-4.5 1.4-4.5 1.6-5.0 1.6-5.0
Motor Kw 75 130 75 75 95 95
Rotor Speed Rpm 1200 850 1000 1000 90 90
Line Speed m/min 120 120 120 120 120 120
Capstan Power kw 37-45 37-45 37-55 37-55 37-55 37-55

  • pay-offs and take-ups, both stationary and traversing
  • pancake and container pay-offs, driven, dancer controlled or fill-factor controlled
  • machine bobbin sizes to requirement
  • pre-form heads for a wide range of production requirements
  • manually or electrically adjustable die stands
  • haul-offs
  • double capstan haul-offs with grooved capstans
  • band type haul-offs with integral tension measurement single capstan haul-offs with manual or electrical fleeting ring adjustment
  • accessories and auxiliary equipment
  • lubricators
  • postformers
  • bobbin loading systems
