DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
DSJ 180 Electric Cable Puller Machine 900KGs Capacity
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
OEM
Model Number :
DSJ
Certification :
ISO9001
MOQ :
5
Price :
$1,200-1,300
Power Source :
Electric
Oversize dimension :
950*500*400 mm
Cable diameter :
30-180mm
Electric motor :
1.1KW * 2
Pulling Speed :
8 m/min
Pulling capacity :
700 KGS
Capacity :
900 KGs
Weight :
180-200 KGS
Transmission ratio :
I=60
Rubber sheet thickness :
25mm
Model Type :
DSJ-180
Line pulling :
900 KGS
Pulling Speed (DSJ-180) :
6 m/min
Electric motor (DSJ-180) :
1.5KW * 2
Oversize dimension (DSJ-180) :
1020*590*400
Description

DSJ 180 Electric Cable Puller Machine 900KGs Capacity

DSJ 180 Electric Cable Puller Machine 900KGs Capacity

DSJ 180 Electric Cable Puller Machine 900KGs Capacity

DSJ 180 Cable Push Pulling Machine to pull electric cables

Application

DSJ 180 Cable Push Pulling Machine we manufactured, is the ideal machine of cable transmission used in power,

petroleum, chemical, industrial construction, power plant extension, substation and city network transmission cable.

It is suitable for cable trays in any form of channel, cable pipe, conveying a variety of power cable and control cable.

Features

Using this kind of this device changes the manual transmission cable. It can save a lot of labor, improve working conditions,

reduce labor intensity, improve work efficiency and ensure the safety.

Technical Data

Model Type DSJ-150 DSJ-180
Line pulling(KGS) 700 900
Pulling Speed(m/min) 8 6
Electric motor 1.1KW *2 1.5KW * 2
Oversize dimension 950*500*400 1020*590*400
Weight(KGS) 150 180-200
Cable diameter Φ30 - 180 mm Φ30 - 200 mm
Transimission I=45 I=60
Rubber sheet thickness 25mm 25mm

DSJ 180 Electric Cable Puller Machine 900KGs Capacity

DSJ 180 Electric Cable Puller Machine 900KGs Capacity

DSJ 180 Electric Cable Puller Machine 900KGs CapacityDSJ 180 Electric Cable Puller Machine 900KGs CapacityDSJ 180 Electric Cable Puller Machine 900KGs Capacity
