10kN Three-Wheel Steel Hoisting Tackle with Galvanized Frame for Tower Erection and Lifting Pulley Applications
10kN Three-Wheel Steel Hoisting Tackle with Galvanized Frame for Tower Erection and Lifting Pulley Applications
10kN Three-Wheel Steel Hoisting Tackle with Galvanized Frame for Tower Erection and Lifting Pulley Applications
10kN Three-Wheel Steel Hoisting Tackle with Galvanized Frame for Tower Erection and Lifting Pulley Applications
Specifications
Brand Name :
XINYA
Model Number :
QHN
Certification :
ISO
Place of Origin :
Jiangsu, China
MOQ :
1pcs
Price :
get latest price
Payment Terms :
L/C,T/T,
Supply Ability :
1000pcs/week
Delivery Time :
10-15 workdays after payment
Packaging Details :
carton
Material :
steel
Rated Load :
10KN
Sheave :
3
Type :
Lifting Pulley
Application :
lifting for Rope Pulley Blocks
Selling Point :
Hook type,single sheave ,double sheave and three sheave
Item :
10kN Three-Wheel Steel Hoisting Tackle For Tower Erection With Galvanized Frame
Description

10kN Three-Wheel Steel Hoisting Tackle for Tower Erection with Galvanized Frame


Overview

The 10kN Three-Wheel Steel Hoisting Tackle is a heavy-duty lifting tool designed specifically for tower erection and transmission line construction. Featuring a galvanized steel frame and a three-wheel (three-sheave) design, it delivers stable load distribution, smooth operation, and high lifting efficiency in demanding outdoor environments.

Definition

The 10kN Three-Wheel Steel Hoisting Tackle is a mechanical hoisting block used to lift, position, and tension materials during tower erection works. With a rated load of 10kN, it uses three steel sheaves to reduce friction, increase mechanical advantage, and ensure safe and controlled lifting operations.

Key Advantages

  • Rated Load Capacity of 10kN
    Suitable for heavy-duty tower erection and power line construction tasks.
  • Three-Wheel Design for Higher Efficiency
    Distributes load evenly, reduces friction, and improves lifting stability.
  • Galvanized Steel Frame
    Provides excellent corrosion resistance and long service life in outdoor conditions.
  • High Safety & Reliability
    Strong steel structure ensures stable performance under continuous load.
  • Low Maintenance & Long Lifespan
    Designed for repeated use in harsh construction environments.

Main Features

  • Rated capacity: 10kN
  • Structure: Three-wheel / three-sheave design
  • Material: High-strength steel with galvanized surface
  • Smooth rotation for reduced rope wear
  • Heavy-duty construction for tower erection applications
  • Suitable for steel wire rope and lifting ropes

Application Areas

The 10kN Three-Wheel Steel Hoisting Tackle is widely used in:

  • Transmission and distribution line tower erection
  • Power line construction and maintenance
  • Lifting and positioning of tower components
  • Substation and utility installation projects
  • Industrial hoisting and rigging operations

Technical Data

Order

number

Model

Number of

sheaves

Rated load

(kN)

Outside diameter

×width(mm)

Weight (kg)

Hoisting point type

11101

QH1GN-1K

1

10

Φ100×31

1.8

G

H


11102

QH1-2

2

10

Φ80×27

1.8

G

H


11103

QH1-3

3

10

Φ80×27

2.1

G

H


11111

QH2-1K

1

20

Φ120×35

2.2

G

H

B

11112

QH2-2

2

20

Φ100×31

2.6

G

H


11113

QH2-3

3

20

Φ100×31

3.7

G

H


11121

QH3-1

1

30

Φ150×39

3.4

G

H

B

11122

QH3-2

2

30

Φ120×35

4.5

G

H


11123

QH3-3

3

30

Φ100×31

4.6

G

H


11131

QH5-1K

1

50

Φ166×40

5.2

G

H

B

11133

QH5-2

2

50

Φ150×39

5.5

G

H


11134

QH5-3

3

50

Φ120×35

5.1

G

H


11141

QH8-1K

1

80

Φ205×49

7.2

G

H

B

11142

QH8-2

2

80

Φ166×40

8.3

G

H


11143

QH8-3

3

80

Φ150×39

7.9

G

H


11151

QH10-1K

1

100

Φ246×60

11.4

G


B

11152

QH10-2

2

100

Φ166×40

10.2


H


11153

QH10-3

3

100

Φ150×39

11.7


H


11161

QH15-1K

1

150

Φ280×65

12.1



B

11162

QH15-2

2

150

Φ205×49

12.8


H


11163

QH15-3

3

150

Φ166×40

11.8


H


11164

QH15-4

4

150

Φ150×39

13.9


H


Uses :applied in line construction to craning weight ,etc.

Features: to adopt aluminum alloy side panel and MC nylon sheave .so it is light .monosheave block is open.
