YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
Specifications
Brand Name :
JinHong
Model Number :
YJV22
Place of Origin :
Anhui China
MOQ :
100m
Price :
5-50 USD/m
Payment Terms :
T/T
Delivery Time :
15-20days
Application :
Underground,Industrial,Construction,overhead,Power Station
Jacket :
PVC,Non,no jacket,PVC or XLPE,PVC/PE
Insulation material :
XLPE,PVC,Rubber,XLPE(XLPO),xlpe or pvc
Conductor material :
Copper,Aluminum,steel core aluminum strand,copper/aluminium,tin plated
Type :
Low Voltage,Medium Voltage,High Voltage,Insulated,Rigid/Flexible round
Standard :
IEC60502,IEC,BS,UL,JIS
Color :
Black,Red,blue,brown,Requirement
Product name :
Medium Voltage Power Cable,Fire Resistant 4core LV Armoured Electrical Cable XLPE Copper Cable,XLPE PVC insulated PVC sheathed 4 core copper power cable,steel tape armoured cable,Aerial Bundled Cable
Conductor :
Copper,Alulminum,Class 2 annealed copper strands,Cu / Al,strand
Insulation :
XLPE,XLPE PE PVC,PVC,PE,XLPE/PE/PVC
Rated voltage :
0.6/1KV,3.6~35kv,8.7/10,3.6/6.6,6/10
Voltage :
0.6/1KV,low voltage,medium voltage,300/500V,450/750V
Core :
1 Core,5 core,duplex/triplex/quadruplex,3,Single
Sheath :
PVC,ZR-PVC,LSOH,Non-sheath,PE
Packing :
Wooden Drum,optional,Wooden-steel Drum
Conductor type :
Stranded,copper
Name :
11KV SWA FIRE RETARDANT CABLE,welding cable,JKLGYJ 1KV overhead power cables
Armour :
Steel wire or Aluminum wire armor,Steel tape armour,STA/SWA/ATA/AWA,or unarmored
Item :
XLPE Copper Cable,Medium voltage XLPE cable
Description
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Applications
YJV22 Armored Power Cable
YJV22 is an XLPE insulated, PVC sheathed, steel tape armored power cable with copper conductors, designed for robust power distribution in environments requiring mechanical protection and reliability.
Cable Construction Breakdown
  • YJ: XLPE (Cross-Linked Polyethylene) Insulation
  • V: PVC Sheath
  • 22: Double Steel Tape Armor
Applications
  • Underground Power Networks: Direct burial in industrial sites, renewable energy farms, and urban infrastructure
  • Industrial Plants: Wiring for motors, transformers, and machinery in high-stress or corrosive environments
  • Critical Infrastructure: Subways, tunnels, bridges, and power stations requiring mechanical protection
  • Outdoor Installations: Cable trenches and fixed routing with protection against environmental damage
Key Advantages
  • Mechanical Robustness: Steel tape armor resists crushing, impact, and rodent attacks
  • High Performance: Copper conductor and XLPE insulation ensure efficient power transmission
  • Durability: Suitable for harsh environments, including direct burial and industrial settings
  • Versatility: Available in single-core/multicore designs with customizable conductor sizes (1.5-1000 mm²)
YJV22 is ideal for projects demanding mechanical protection and reliable power distribution. For enhanced fire safety, consider NH-YJV22 (fire-resistant) or WDZ-YJV22 (LSZH) variants. Consult technical datasheets or contact our team for specific requirements.
Technical Specifications
Nominal Sectional Area (mm²) Insulation Thickness (mm) Sheath Thickness (mm) Approx. Diameter of Cable (mm)
3×25 3.4 1.3 48.34
3×35 3.4 1.3 50.70
3×50 3.4 1.4 53.48
3×70 3.4 1.5 57.55
3×95 3.4 1.5 60.77
3×120 3.4 1.6 64.41
3×150 3.4 1.7 67.93
3×185 3.4 1.7 71.91
3×240 3.4 1.8 77.49
3×300 3.4 1.9 83.06
3×400 3.4 2.0 90.46
3×500 3.4 2.2 99.47
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
YJV22 Armored Power Cable 3*50/70/95 Square 8.7/15kV High Voltage Cable
Service of JinHong Company
Over Productions Service:
JinHong has a wide range of cable and conductor products for you to choose from. We will provide caring services and professional project solutions for everyone who needs them.
Quality Certification Services:
JinHong cable products are manufactured according to GB, IEC, BS, NFC, ASTM, DIN, and other international standards. Our technical team can customize cable products that meet your requirements according to your needs.
Profession Customer Service:
JinHong provides free professional consulting services to provide you with one-stop project solution services and rapid product delivery solutions.
Delivery And Shipping Services:
While we at JinHong provide high-quality cables, we also provide good delivery solutions. While ensuring the safe delivery of products, we provide the best packaging and transportation solutions, greatly reducing customers’ transportation costs.
Packaging of JinHong:
JinHong cable packaging is provided in the form of wooden reels, corrugated boxes, and coils. The cable ends are sealed with BOPP self-adhesive tape and a non-hygroscopic sealing cap to protect the cable ends from moisture. We can print the required marks on the outside of the barrel with waterproof material according to customer requirements.
